1 MAIN LEVEL
Main volume control of the 2.1 loudspeaker system. Volume of subwoofer and satellites affected in same
way.
2 SUB PHASE
Inverts the phase of subwoofer (0°, 180°).
3
SUB LEVEL
Volume control of subwoofer. Adjust the volume of the subwoofer in relation to satellites. Recommended
setting centre position (12:00h).
4 LINE INPUT (LEFT/RIGHT)
Unbalanced RCA line input.
5
LINE INPUT (LEFT/RIGHT)
Balanced XLR/6.3 mm jack (combo) line input.
6 SAT POWER OUT (LEFT/RIGHT)
Powered Speakon compatible output for LD DAVE G³ series.
7 POWER
Power ON/OFF switch. Before switching power on, all level controls should be set to minimum.
8
MAINS SOCKET (VOLEX POWER PLUG)
With built-in fuse holder AC connection via IEC connector (220 - 240V AC).
A power cord with a lockable Volex connector is supplied with this unit.
IMPORTANT: Replace fuse only by fuse of same type and rating! If fuse blows repeatedly please contact
authorized service center!
9 ON LED
Lights up when power is switched on and mains cable is connected correctly.
10
SIGNAL LED
Lights up when the unit receives an audio signal.
11 LIMIT LED
Lights up when the loudspeaker is operated at its limit. Short-term blinking of the LED is not critical.If the
limiter LED lights up longer than a brief moment or permanently (= over-driving the system), reduce the
volume of the connected signal source. Non-co mpliance will lead to unpleasant and distorted sound and
may cause malfunction of the speaker system.

CONTROL ELEMENTS:
