Move Refrigerator into House
WARNING
Tip Over Hazard
Refrigerator is top heavy and tips easily when not
completely installed.
Keep doors taped closed until refrigerator is
completely installed.
Use two or more people to move and install
refrigerator.
Failure to do so can result in death or serious injury.
When Moving Your Refrigerator:
Your refrigerator is heavy. When moving the refrigerator
for cleaning or service, be sure to cover the floor with
cardboard or hardboard to avoid floor damage. Always pull
the refrigerator straight out when moving it. Do not wiggle
or "walk" the refrigerator when trying to move it, as floor
damage could occur.
1.
Place an appliance dolly under the left side of the refrigerator
as shown. Be sure to avoid damaging the side trims and
handles. Place the corner posts from the packing materials
over the trims and handles as appropriate. Pass the dolly
strap under the handles and slowly tighten the strap.
2.
Place pieces of the shipping carton on the floor when rolling
the dolly and refrigerator into the house. Move the refrigerator
close to the opening.
3.
Place cardboard or plywood under the refrigerator.
4.
Stand the refrigerator up. First, place the left bottom edge of
the refrigerator on the floor, stand the refrigerator upright and
then lower the right-hand side of the refrigerator to the floor.
Installation Instructions
Reinstalling the Doors
After the moving the refrigerator to the location where it will be
used, reinstall the doors and freezer drawer front.
1.
Replace the rollers.
2.
Slide the screws on the
back of the drawer front
into the slots in the drawer
brackets on both sides.
You may need to move
the bottom of the bracket
around slightly to get the
slot to line up with the
screw.
3.
Tighten the four front panel
screws completely. Do not
over-tighten.
4.
Install the top hinge loosely using the existing hex head
screws.
5.
Install the center hinge using the existing Phillips screws.
Top hinge
6.
Place the hinge side of the refrigerator
door on the center hinge pin.
7.
Align each door so that the bottom of
the refrigerator door aligns evenly with
the top of the freezer drawer. While
holding the refrigerator door upright,
tighten down the top hinge with a hex
head driver.
8.
Reconnect the wiring plug located
on top of the left top hinge.
9.
Replace the top hinge cover using
the existing Phillips screw.
10. Return all removable door parts
to the door and food to the
refrigerator.
Shim
Center hinge
Hinge pin
Wiring plug
Hinge cover
5
