of fall.
When the tree begins to fall remove the chain saw from
the cut, stop the motor, put the chain saw down, then use
the retreat path planned. Be alert for overhead limbs fall-
ing and watch your footing.
d) Limbing a Tree
Limbing is removing the branches from a fallen tree.
When limbing, leave larger lower limbs to support the log
off the ground. Remove the small limbs in one cut as il-
lustrated in Figure 12. Branches under tension should be
cut from the bottom up to avoid binding the chain saw.
e) Bucking a Log
Bucking is cutting a log into lengths. It is important to
make sure your footing is firm and your weight is evenly
distributed on both feet. When possible, the log should be
raised and supported by the use of limbs, logs or chocks.
Follow the simple directions for easy cutting.
When the log is supported along its entire length as il-
lustrated in Figure 13, it is cut from the top (over-buck).
When the log is supported on one end, as illustrated in
Figure 14, cut 1/3 the diameter from the underside (un-
derbuck). Then make the finished cut by overbucking to
meet the first cut.
When the log is supported on both ends, as illustrated in
Figure 15, cut 1/3 of that diameter from the top overbruck.
Then make the finished cut by underbucking to meet the
first cut.
When bucking on a slope always stand on the uphill
side of the log, as illustrated in Figure 16. When "cutting
through", to maintain complete control release the cutting
pressure near the end of the cut without relaxing your grip
on the chain saw handles. Don't let the chain contact the
ground. After completing the cut, wait for the saw chain
to stop before you move the chain saw. Always stop the
motor before moving from tree to tree.
Spiked bumper (Fig. 17)
• Dig the spiked bumper into the log and use it as a
pivot. Cut with an arched motion to make the bar pen-
etrate the wood.
• Repeat several times if necessary, changing the point
where you plant the spiked bumper.
Maintenance and Servicing
Always withdraw the plug when carrying out
maintenance and servicing.
• Always remove wood shavings and oil from your chain
saw after use. Ensure in particular that the motor ven-
tilation slits for cooling the motor in the housing of the
chain saw is free (danger of overheating).
• If the saw chain is particularly dirty, e.g. in case of
gumming with resin, remove the chain and clean it.
Place the chain for a few hours in a vessel containing
chainsaw cleaner. There-after clean the chain with
clear water. If the chain is not used again immediately,
it must be treated with service spray or a customary
anticorrosion-spray.
• Only in case of use of biological oil: As some biological
oils may tend to encrust after a time, the oiling system
should be rinsed thoroughly before storing the chain
saw for a longer period. Therefore, please fill half of
the oil reservoir (about 50 ml) with chainsaw cleaner
and close it as usual. Then switch on the chainsaw
- without bar and chain being mounted - and keep it
running until the total rinsing liquid has evaporated
through the oil opening of the chain saw. Before using
the chain saw again, it is absolutely necessary to refill
the oil reservoir.
• Do not store the saw outdoors or in damp and moist
areas.
• Check all the chain saw parts, in particular the chain,
bar and sprocket, of wear after every use.
• Ensure that the chain tension is correct. If the chain
is too loose, it may come off during use and lead to
injuries. The chain must be replaced immediately if it is
damaged. The cutting teeth must be at least 4 mm long.
• •Check the motor housing and power cable after every
use for damage. If there is any sign of damage, have
the chain saw checked by a specialised workshop or
the works after-sales service.
• Check the oil level and lubrication of your chain saw
after every use. Insufficient lubrication leads to dam-
age to the chain, bar and motor.
• Check how sharp the chain is every time before you
use the chain saw. A blunt chain will cause overheat-
ing of the motor.
• Sharpening a saw chain requires experience and spe-
cialised knowledge. We therefore recommend to have
sharpening carried out by a specialised workshop.
• Before transporting the chainsaw, always remove the
plug from the power socket and slide the chain guard
over the rail and chain. If several cuts are to be per-
formed with the chain saw, the saw must be switched
off between cuts.
• When using a vehicle to transport the machine, posi-
tion it so that it can cause no danger to persons and
fasten it firmly.

In the case of technical problems

• The machine does not start up: Check whether the
current socket is live. Check whether the power cable
is undamaged. If neither case applies, take the chain
saw to a specialised workshop or the works after-sales
service.
• Chain does not run: Check position of handguard
(see ill. 8). Chain only runs if handguard brake is re-
leased.
• Sparks fly at the motor: Motor or carbon brushes
damaged. Take the chain saw to a specialised work-
shop or the works after-sales service.
• Oil does not flow: Check the oil level. Clean the oil
flow openings in the bar. If this is not successful, take
the chain saw to a specialised work-shop or the works
after-sales service.
Attention: Any maintenance or repair work go-
ing beyond that described in these Operating
Instructions may only be carried out by author-
ised persons or the works after-sales service.
Attention: If the power supply lead of this device
shows any defects, the lead must be replaced
by an authorized repair shop only or through
GB-8
