KickBack Control (Rapid Shut-off)
To ensure better control of the tool during
operation, this tool is design to shut-off
while in use if a sudden or unexpected
bind up situation occurs. Bind up occurs when the
bit gets jammed during operation, which forces
the bit to stop spinning abruptly. If this occurs, the
tool will shut down and the KickBack Control will
be indicated by flashing LED lights on the tool.
The sensitivity level of this feature is adjustable.
Using Bosch Toolbox app on a mobile device,
operator may select one of three settings between
"Earlier" and "Later" markers on the app. The
settings only control the KickBack Control
activation delay, and do not change the capacity
of this feature.
When the switch trigger is pressed, operator is
notified about the KickBack Control settings, by
the work light and function red light identified in
Fig. 1 on page 8.
The setting indications are as follows:
Continuous white light (W) = Later (delayed
W
Kick Back activation).
To reduce the risk of injury read the operating instructions included with
Bosch GCY30-4 connectivity module. Operating instructions for GCY30-4
connectivity module include important information not covered in this manual.
BLUETOOTH®
Do not use the power tool
with Bluetooth® in the
vicinity of gas stations, chemical plants, areas
where there is danger of explosion and areas
subject to blasting. Do not use the power tool
with Bluetooth® in airplanes. Do not use the
power tool with Bluetooth® in the vicinity of
medical devices. Avoid operation in the direct
vicinity of the human body over longer
periods of time. When using the power tool with
Bluetooth®, interference with other devices and
systems, airplanes and medical devices (e.g.,
cardiac pacemakers, hearing aids) may occur.
The Bluetooth® word mark and logos are
registered trademarks owned by Bluetooth SIG,
Inc. and any use of such marks by Robert Bosch
Tool Corporation is under license.
Follow all instructions and
warnings provided by your
Bluetooth® device manufacturer. Failure to
follow recommended procedures could result in
personal injury or property damage.
Slow alternating red (R) and white (W)
R W R W
light = Mid-Level (less delayed activation).
Fast alternating red (R) / white (W) light =
R R R R W W W W
Earlier (minimum delay to activation).
The label next to the work light displays the Kick
Back setting indicator light pattern.
This feature can only be activated when the tool is
running at maximum speed.
NOTE: The default KickBack Control setting for
the tool is "Later". KickBack Control setting for the
tool without GCY30-4 module installed is always
set to default.
Connectivity
devices to control or change power tool
functions. Operation of the device may be in a
different area than the paired power tool. Paired
devices may have functionality which allows timed
event programming, including automatically
powering on (e.g. flood light). Depending upon the
power tool, these unattended operations or
function changes without direct line of sight to the
paired tool could result in personal injury or
property damage.
different than when the tool was last used. The
connectivity module enables transfer of data and
settings based on Bluetooth® wireless
technology. With module installed, select tool
settings may be changed remotely by a paired
Bluetooth® device and user installed app.
radio interface. Local operating restrictions, e.g. in
SAVE THESE INSTRUCTIONS
RED LIGHT WHITE LIGHT
Exercise extreme caution
when using Bluetooth®
Always check tool settings
before use. Settings may be
The connectivity module
GCY30-4 is equipped with a
