4.3 Assembly
ASSEMBLING THE TRACK (Fig. 3)
Join the two halves of the track using the coupling (verify the proper insertion side), and push until the stopper in the track is reached.
ADJUSTING THE BELT-TENSIONER (Fig. 4)
The belt's tension must be adjusted using the tensioner on the end of the track. In order to avoid damaging the automation's mechanical
components, the belt must not be overtightened.
MOUNTING THE TRACK ON THE CEILING (Fig. 7)
Mount the belt track in the centre with respect to your door.
Note: The centre of the garage and the centre of the door may be different.
Use tools and fastening materials that are suitable for the installation site's conditions.
ASSEMBLING THE MOTOR HEAD ON THE CEILING TRACK (Fig. 6)
Align the motor head: Align the motor head's front attachment with the support on the track, and insert it; Secure the motor head against
the risk of falling. If it cannot be inserted perfectly: turn the belt/chain drive pulley slightly and try again. Screw in the motor head using
the supplied screws and toothed washers.
4.4 How to release the gear motor (Fig. 5)
In the event of a malfunction or power failure, the motor can be released as shown in Fig. 5a or 5b in order to move the door manually.
CAUTION The safety and efficacy of moving the automation manually is only guaranteed by DEA System if the system has been
properly installed using original accessories.
