UNPACKING
1. Remove the box and all packing materials from around the unit.
NOTE: Save all packing materials until you are completely satisfied all parts of the unit are
operating satisfactorily and just in case the unit should need service in the future.
2. Make sure you have located all accessories supplied before storing away the packaging.
3. Make sure you have located the Remote Control. This can be stored on the magnetic panel
on the side of the unit.
4. Remove the plastic safety cover from the AC plug.
5. Remove the tie from the AC Power Cord and unravel the antenna wire on the back of the unit.
6. Open the lid and remove the Polyfoam shipping material from the turntable.
7. Remove the black tie-wrap from around the Tone Arm.
8. Remove any tape and the white protective needle cover by gently pulling it forwards and off the Tone Arm.
This should expose the red Stylus Cartridge.
9. Release the Tone Arm Hold-down Clip by gently pushing it off to the right.
This will unlock the Tone Arm from its arm rest.
NOTE: Re-lock the hold down clip when moving the unit to another location.
POWER SOURCE
Unwind the AC POWER CORD at the back of the unit and connect the plug into a suitable 230v AC Power outlet.
HEADPHONE JACK OPERATION
To listen through Earphones or Headphones (not supplied), plug them into the Headphone Jack.
Adjust the volume to a safe level.
NOTE: The sound from the internal speakers will be cut off when Headphones are attached.
GENERAL
1. Make sure the unit is correctly plugged into a 230V AC outlet.
2. The red STAND BY LED will light up. This shows there is power going into the unit.
3. Press the POWER button /
4. The blue LED Backlight will light up and the Tuner Dial will light up for a second.
This will stay lit when the Tuner function has been selected.
5. " HELLO " will show on the Display, then ―TUNER FM‖ will show
6. Press the FUNCTION button /
NOTE: When switching between functions, after pressing the function button, wait for one second before pressing it
again. This gives the unit time to load the correct information for the selected function. Repeatedly and too quickly
pressing the button(s) on this unit may cause the system to lock up.
RADIO OPERATION
1. Press the FUNCTION button /
2. Press the BAND button /
3. Select the desired radio station by rotating the TUNING KNOB.
4. Adjust the volume to the desired listening level.
ANTENNA
For FM reception, the unit is provided with a WIRE ANTENNA. Move the wire until radio reception is clear and there is
no interference. NOTE: If Stereo FM reception is not good, it may be better to switch to Mono Sound:
Press the Mono/Stereo Button /
For AM (= MW) reception, the unit is provided with a directional built-in ferrite antenna. Rotate the set to find the
position in which the best reception is obtained.
CAUTION: Do not connect the EXTERNAL WIRE FM ANTENNA to any outside antenna.
to turn the unit on.
to switch between Tuner ->CD->Phono->CD/AUX.
to select TUNER MODE. The Dial will light up.
to select the desired tuning band: AM (= MW) or FM.
on the Remote to select Mono reception.
