Aux Input
Using the Aux Input allows you to connect additional external audio components and
listen to them through your unit. Any component with an audio output, such as a
Radio, MP3 Player, etc. can be connected by using the correct cables (included). This
unit uses standard RCA cables.
1. Press the FUNCTION button /
2. Plug the Red and White connectors on one end of the cable into the corresponding
Red and White Aux-in Jacks on the back of the unit.
3. Plug the other end of the cable into the Audio Output Jack of the other unit.
For more information on how to connect to and operate the other unit, see the
owner's manual for that unit.

Audio Output

Using the Audio Output will allow you to run audio from your unit into another home
Stereo System, Television, Amplifier or other stereo source. To make this
connection, you will need standard RCA cables.
1. Plug the Red and White connectors on one end of the cable into the corresponding
Red and White Audio Output Jacks on the back of this unit.
2. Plug the other end of the cable into the Aux Input Jacks of your selected other
stereo unit. For more information on connecting to the other unit, see the owner's
manual for that unit.
NOTE: When using the Audio Output feature, you can still hear the sound through
the built-in Stereo speakers of this unit as well as through the other stereo system.
EQ
Press the EQ button/
There are 5 EQ Modes, the sequence is as shown below:
TROUBLESHOOTING
Q There is no Power going into the unit
A Make sure the unit is plugged in correctly, into a 230v AC Mains outlet.
A Check to make sure the unit is on and not in Standby Mode by pressing the POWER button.
Q There is no sound coming from the unit
A Check the volume level by turning the volume knob or by pressing /
A Check you did not leave any Headphones plugged in – this will cut all sound from the speakers.
Q There is no sound when playing recorded Discs
A Make sure the volume has been set at the desired level before playback or before you begin recording. You cannot
adjust the volume sound level once you begin recording to CD.
Q Turntable will not work
A Make sure the unit is set to ―Phono‖ Mode by pressing the Function button.
A Make sure the chrome Turntable Suspension Screw is screwed all the way down.
A Check the Cassette Player is not on as both Phono and Tape work in the same ―Phono‖ Mode. If in doubt, remove
any cassette still in the cassette player.
A Make sure the Turntable Drive Belt has not come off. To replace the belt, see separate Instructions and line
drawings.
Q Turntable – the sound is low when playing a record
A Remove and refit the stylus
to select CD/AUX mode.
repeatedly to choose the desired sound field.
on the Remote.
