Receiver - Wall-Mounted Shutter Module
To erase
This procedure consists of erasing all addresses you may entered
over time which are not valid to control your Home Automation
system.
1. Take off the paddle from the receiver.
2. Press and hold the PROG key till LED lights up green (after 3
seconds).
3. Release PROG key. Both green and red LEDS blinks quickly on, to
turn off after several seconds (LED to blink orange). Time to erase
depends on the number of entered valid addresses.
4. All addresses are now erased, receiver goes back in X10 standard
communication protocol.
5. Put on again the paddle (make sure ebode logo is located on the
bottom right side).
Operating the RMV receiver
Gently press the upper key (ON) to go up.
Gently press the lower key (OFF) to go down.
Use a X10 compatible remote control, RF wall switch or programmer to
check remote control of the shutter, roll blind or motorized screen.
Troubleshooting:
www.ebodeelectronics.eu.
RMV cannot be controlled anymore from either an RF or PLC remote/
programmer?
- Check and/or change the battery of your remote.
- Go for an overall RESET of the receiver as it may have lost the address due to
too many manipulations (starts from point 5), then re-initialize transmitter and
receiver RMV both together (starts from point 3).
Red or Green LED blinks randomly even if no commands are given:
RF or PLC interference may occur (ie Fluo lamps, Reversible A/C, PC monitor)
please add either a filter FD10 in the main control panel or a plug in module FM10
to filter the product in cause.
July 2009
all recorded adresses on the receiver (overall RESET).
