1. Introduction

The Ambu® Man Basic is an instruction and training manikin for the simulation of realistic
conditions during cardiopulmonary resuscitation by means of rescue breathing and chest
compression moreover the AmbuMan Basic will cover all aspect of basic life-support
training.
The manikin incorporates a unique, patented hygienic system under which all trainees get
their own face piece and head bag, thereby minimizing any risk of cross-infection
between the trainees. The hygienic system also features realistic expiration from the
manikin through the mouth and nose.
With the special hygienic system, disassembly and internal cleaning and disinfection are
rendered unnecessary both during and after training. The manikin has the size of a normal
adult and provides an exceptionally lifelike representation of the human anatomy,
particularly of those features important to training in modern resuscitation techniques.

2. Specifications

Weight: 12 kg
Dimensions (L x W x H): 70 x 37 x 25 cm
Maximum chest compression: 7,5 cm
Part/Material
Basic unit
Instrument part
Skull
Chest skin
Face piece
Head bag, disposable
Training suit
Carrying bag/training mat
Usage and storage:
Storage temperature (non-condensing): –18 °C (-0,4 °F) to 40 °C (105 °F)
Usage temperature (non-condensing): –5 °C (23 °F) to 40 °C (105 °F)
Humidity: 5 % to 95 %

3. Functions

3.1 Hygienic System ①
Schematic diagram:
The head bag has been mounted in the skull and the face piece fitted.
Ventilation has just started, see (1.1).
A: Trainee's air B: Ambient air
4
Polyethylene
ABS plastic
PVC, hard
PVC, soft
PVC, soft
Polyethylene
50 % cotton and 50 % polyester
nylon material
