Connections
You can connect your stereo amplifier to your LCD monitor. Refer to your amplifier's owner's manual for additional information.
• Turn on the LCD monitor and the amplifier only after all connections have been made.
• Use an RCA cable to connect the AUDIO OUT connector (RCA) on the LCD monitor and the audio input on the amplifier.
• Do not reverse the audio left and right jacks.
• The AUDIO IN used for audio input.
• The AUDIO OUT jack outputs sound from the Audio input device (VCR) selected by the LCD monitor to the
external output device (stereo amplifier).
Denotes an AV unit function.
AV
All AV functions are enabled when the AV unit is installed.
–continued
