1
Power / Delay Off
/
1
1
Power / Delay Off Button
-
/
Button will turn power on and off for entire hood (fan and lights.)
- Hood will remember the last speed and light level it was last turned off at.
(Example: Press
Press
button again and the hood will turn back on at speed 3 and high lights.)
/
Delay Off
- With the fan on, press and hold the
/
speed 1, the
button will blink on and off indicating the 5 minute delay off timer has started.
/
- Pressing
button while delay off function is enabled will turn the hood off and cancel
the delay off function.
ACT Verification
- Airflow Control Technology (ACT) allows the installer to set the maximum fan CFM to align with
local codes and regulations.
- To verify the maximum fan CFM:
- With hood off, hold the
illuminate = default maximum CFM. If speed level 1 and 2 indicators illuminate = 390
maximum CFM. If only speed level 1 indicator illuminates = 290 maximum CFM.
2
Lights Button
- Lights are two levels, high and low.
- From off, press one time for high. Press again for low. Press again to power lights off.
3
Speed Level Indicators
- Fan is three speed levels. 1 for low speed, 2 for medium speed, and 3 for high speed.
2
3
3
Speed Indicators
/
/
button to turn off hood when on fan speed 3 and high lights.
/
button for two seconds. The fan will change to
/
button for five seconds. If all three fan speed indicators
18
www.zephyronline.com
2
Lights On/Off
