KNOW YOUR PRODUCT

See page 93.
1. Turn off
2. Variable speed control selector
3. Turn on
4. Cover
5. Finger pad
6. Lock
7. Dust collection box
8. Delta pad
9. Paper Clamp
10.
11. Hex key
12. Adhesive sandpaper
13. Non-adhesive sandpaper
14. Insulated grasping surface
SANDPAPER SELECTION
Selecting the correct size, grit and type of sand paper is an
extremely important step in achieving a high quality sanded
abrasives are best for power sanding. Natural abrasives,
power sanding.
In general, coarse grit will remove the most material
operations. The condition of the surface to be sanded will
start with a coarse grit and sand until the surface is uniform.
Medium grit may then be used to remove scratches left
surface. Always continue sanding with each grit until
surface is uniform.
WARNING
Do not use sander without sandpaper; doing so will
damage the cushion.
Sheet/pad recommended use
80-grit sanding sheet
120-grit sanding sheet
150-grit sanding sheet
MAINTENANCE
WARNING
The product should never be connected to a power
cleaning, performing maintenance, or when the product
is not in use. Disconnecting the product from the power
supply will prevent accidental starting that could cause
2 | English
When servicing, use only original manufacturer's
replacement parts, accessories and attachments. Use of
any other parts may create a hazard or cause product
damage.
based products, penetrating oils, etc., come in contact
with plastic parts. Chemicals can damage, weaken or
destroy plastic which may result in serious personal
accelerated wear and possible premature failure
abrasive to bearings, brushes, commutators, etc. We do
not recommend using the product for extended work on
these types of materials.
Do not use compressed air to blow dust from the product.
Coarse sanding
This practice is dangerous and can cause dirt and grit to
Light sanding
Light sanding
LUBRICATION
All of the bearings in the product are lubricated with a
the product under normal operating conditions. Therefore,
no further lubrication is required.
CLEANING THE SANDING SHEETS
The sanding sheets that come with the product are made to
be re-used. Therefore, it is important that they be cleaned
periodically to remove sanding residue and foreign material
that can accumulate over time.
To clean sanding sheets, rub the sheets with a hard rubber
block. You can also use the clean rubber sole of a shoe.
WARNING
WARNING
Avoid using solvents when cleaning plastic parts. Most
plastics are susceptible to various types of commercial
solvents and may be damaged by their use. Use clean
cloths to remove dirt, carbon dust, etc.
Always wear safety goggles or safety glasses with side
shields during power tool operation or when blowing
dust. If operation is dusty, also wear a dust mask.
If the supply cord is damaged, it must be replaced
by a special cord or assembly available from the
manufacturer or its service agent.
For greater safety and reliability, all repairs should be
performed by an authorised service centre.
WARNING
WARNING
