8.4 Functions of the DMX channels
GB
Important: For the DMX control of the unit the
adjusted address (
system menu.
Table 1 3-channel mode
Channel Function for DMX Value 0 → 255
red
1
green
2
blue
3
Table 3 8-channel mode
Channel Function for DMX Value 0 → 255
operating mode
1
2 speed
(when channel 1 = value 8 ... 231)
red
3
green
4
blue
5
red
6
green
7
blue
8
* Brightness for the operating modes "Dimmer" and "Stroboscope"
(when channel 1 value 0 ... 15)
16
...) must be selected in the
brightness 0 % → 100 %
-
brightness 0 % → 100 %
-
brightness 0 % → 100 %
-
see table 7
slow → fast
brightness* 0 % → 100 %
-
brightness* 0 % → 100 %
-
brightness* 0 % → 100 %
-
brightness* 0 % → 100 %
-
brightness* 0 % → 100 %
-
brightness* 0 % → 100 %
-
Table 2 5-channel mode
Channel Function for DMX Value 0 → 255
operating mode
1
2 speed
(when channel 1 = value 8 ... 231)
red
3
green
4
blue
5
* Brightness for the operating modes "Dimmer" and "Stroboscope"
(when channel 1 value 0 ... 15)
Table 4 14-channel mode
Channel Function for DMX Value 0 → 255
operating mode
1
2 speed
(when channel 1 = value 8 ... 231)
red
3
green
4
blue
5
red
6
green
7
blue
8
red
9
green
10
blue
11
red
12
green
13
blue
14
* Brightness for the operating modes "Dimmer" and "Stroboscope"
(when channel 1 value 0 ... 15)
see table 7
slow → fast
brightness* 0 % → 100 %
-
brightness* 0 % → 100 %
-
brightness* 0 % → 100 %
-
see table 7
slow → fast
brightness* 0 % → 100 %
-
brightness* 0 % → 100 %
-
brightness* 0 % → 100 %
-
brightness* 0 % → 100 %
-
brightness* 0 % → 100 %
-
brightness* 0 % → 100 %
-
brightness* 0 % → 100 %
-
brightness* 0 % → 100 %
-
brightness* 0 % → 100 %
-
brightness* 0 % → 100 %
-
brightness* 0 % → 100 %
-
brightness* 0 % → 100 %
-
