Electrical Connection; Ingress Protection - WIKA air2guide A2G-45 Mode D'emploi

3. Specifications

Electrical connection

Cable gland M16 and M20, screw terminals max. 1.5 mm²
Output signal
0 ... 10 V, 2-wire, load resistance min. 1 kOhm
Voltage supply
AC 24 V ±10 % or DC 21 ... 35 V
Long-term stability
≤ ±8 Pa
≤ ±1 Pa with automatic zero adjustment (option)
Dimensions in mm

Ingress protection

IP 54 per EN 60529 / lEC 529
For further specifications see WIKA data sheet SP 69.08 and the order
documentation.
WIKA operating instructions air2guide model A2G-45
Weight
150 g
7
GB
