Alarm 1 configuration Hexadecimal
Alarm 1 - high thres- Hexadecimal
hold
Alarm 1 - hysteresis of Hexadecimal
high threshold
Alarm 1 - low threshold Hexadecimal
Alarm 1 - hysteresis of Hexadecimal
low threshold
Alarm 2 configuration Hexadecimal
Alarm 2 - high thres-
hold
Alarm 2 - hysteresis of
high threshold
Alarm 2 - low threshold
Alarm 2 - hysteresis of
low threshold
Alarm 3 configuration Hexadecimal
...
Alarm 4 configuration Hexadecimal
...
Alarm 5 configuration Hexadecimal
...
Alarm 6 configuration Hexadecimal
...
Alarm 7 configuration Hexadecimal
...
Alarm 8 configuration Hexadecimal
...
Alarm 9 configuration Hexadecimal
...
Alarm 10 configuration Hexadecimal
...
Default : 0 (deactivated)
Bits 0 to 1 : Active thresholds
• 1 : Low threshold
• 2 : High threshold
• 3 : High and low thresholds
Bit 2 : Modbus register type
• 0 : holding registers (read/write)
• 1 : input registers (read only)
Bit 3 : Reserved
Bits 4 and 5 :Data type
• 0 : 16-bit unsigned integer
• 1 : 16-bit signed integer
• 2 : 32-bit unsigned integer
• 3 : 32-bit signed integer
Bits 6 ,and 7 : Reserved
Bits 8 to 23 : Adresse du 1er registre
Bits 8 to 23: First register address
Bits 24 to 31: Slave address:
• 0 : alarm deactivated
• 1 à 247 : slave address
Default: 0
Min/Max : 0 to 0xFFFFFFFF
Unit : none
Default: 0
Min/Max : 0 to 0xFFFF
Unit : none
Default: 0
Min/Max : 0 to 0xFFFFFFFF
Unit : none
Default: 0
Min/Max : 0 to 0xFFFF
Unit : none
See registers 340 to 344
See registers 340 to 344
See registers 340 to 344
See registers 340 to 344
See registers 340 to 344
See registers 340 to 344
See registers 340 to 344
See registers 340 to 344
See registers 340 to 344
