Transportation cap
4
46
R 17
Let the heater cool down.
2
Clean the heater with a damp cloth and then dry it with a dry cloth.
3
Remove the batteries from the holder ¹ and store them in a dry place.
4
Clean the fuel filter (refer to section H).
5
Store the heater in a dust-free place, if possible in its original packaging.
6
Unused fuel cannot be used for the next heating season. If there is still some
fuel left, do not throw it away, but dispose of it in accordance with the local
regulations for the disposal of domestic chemical waste. Always start the new
heating season with fresh fuel. When you start re-using the heater, follow the
instructions again (starting from Section A and as specified).
TRANSPORTATION
Take the following measures to avoid fuel leakage during the transportation of
the heater:
Let the heater cool down.
1
Remove the removable tank ¾ from the heater and remove the fuel filter
2
(Fig. N). Some drops may leak from the filter; keep a cloth at hand. Store the
fuel filter and the removable tank outside the heater.
Place the transportation cap into the position of the fuel filter (Fig. O).
3
Press it tight.
4 Always move the heater in an upright position.
SPECIFICATIONS
Ignition
Fuel
Capacity (kW)
*
Suitable space (m )
3 **
Fuel consumption (l/hr) *
Fuel consumption (g/hr) *
Burning time per tank (hr)
Capacity removable tank (litres) 4.0
Weight (kg)
* At maximum setting
** Specified values are indicative
electrical Dimensions (mm)
paraffin (including base plate) depth
3.00
85-110 Accessories:
0.313
250
* 12.8 Required batteries
9.0 Wick type
width 428
295
height 513
manual fuel pump
transportation cap
2x R20kG, MN 1300
1.5V, size D
