2.
Press and hold "ON" button on the remote
controller until receiver "beeps" twice. (If you are
using multiple remotes, perform step 2 on each
remote before proceeding.)
3.
Press and hold reset button (C) for 3 seconds until
receiver "beeps" 3 times.
The remote controller is now ready.
6.3 Dust hose connection
Use proper type hose to connect dust collector to
machine(s) being operated. Dryer vent hose is not
acceptable for this purpose. Secure hose at both ends
with proper clamps.
If an inlet port is not being used, it should remain
capped. An open port will diminish the machine's
efficiency, and may create a safety hazard.
Contact your nearest JET distributor for a line of Dust
Collector hoses and accessories. You can customize
your installation and obtain maximum performance
with dust hoods, hoses, clamps, fittings, and blast
gates.
7.0 User-maintenance
Turn OFF dust collector and
remove plug from power source before performing
any adjustments or maintenance. Failure to comply
may result in serious injury.
7.1 Thermal overload reset
The switch box contains overload protection to help
prevent damage to the motor. The relay will open the
circuit (shut off the dust collector) if the motor is
drawing excessive current during extended periods of
operation.
If the overload is tripped, allow the machine to cool
down for several minutes.
1.
Remove screw on switch box and remove cover.
2.
Press reset button (A, Figure 17) to reset the
overload relay
3.
Close switch box cover and tighten screw to
secure.
7.2 Cleaning and bag inspection
Clean canister filter frequently to keep the collector's
performance at its optimum. To clean filter, turn
handle a couple of rotations so dust falls into attached
collection bag.
Empty or replace canister and drum collection bags
when full.
ATTENTION:
During the changing or cleaning of the filters it's
necessary to use a mask (mask with filtration).
7.3 Motor inspection
Make frequent inspections of motor fan, and blow out
(with low pressure air hose) or vacuum any
accumulation of foreign material to maintain normal
motor ventilation.
7.4 Additional servicing
No lubrication is required for the dust collector.
Any other servicing should be performed by an
authorized service representative.
14
Figure 17
