ON
Infra
OFF
4CH
Addr
9CH
Slav Slav
dISP
Disp
d. S IP
AUTOMATIC CONTROL:
Press the "Menu" button repeatedly until the display shows "Auto". Now the unit plays the automatic program.
Press "Enter" again to select "AU-1" to "AU-6". With the "Up" and "Down" buttons you can now set the desired
automatic program.
MUSIC CONTROL:
Press "Menu" until "Sound" is displayed. Sound mode is activated. Press "Enter" again to select sound program
"SO-1" to "SO-6". With the "Up" and "Down" buttons you can now set the desired sound program.
PROCEDURE OF THE PROGRAM:
Press the "Menu" button until "SPED" appears on the display. The flow rate menu is displayed. Press "Enter"
again to select the speed "SP-1" to "SP-9". With the "Up" and "Down" buttons you can now set the desired speed
of the program.
MICROPHONE DETECTION:
The sensitivity with which the headlamp reacts to the music signals (bass impulses).
Press the "Menu" button until "Sens" is displayed. The microphone sensitivity menu is displayed. Press "Enter"
again to select the microphone sensitivity "SE-1" to "SE-9". With the "Up" and "Down" buttons, you can now set
the desired microphone sensitivity. The height is the value, the more sensitive the microphone reacts to the music
signals (bass impulses) in the environment.
SILENT MODE:
The Silent mode refers to the music-controlled operation and is also known as Intelligent Sound Control. If the
silent mode is activated "ON" and the microphone of the device does not receive any music signals (bass
impulses), the light beams of the device switch off (BLACKOUT). If the silent mode is deactivated "OFF", the
current program of the device will continue slowly, even if no further music signals (bass impulses) are received.
Press "Menu" until "SILE" is displayed. The menu for silent mode is displayed.
Press "Enter" again to select "ON" or "OFF". With the "Up" and "Down" buttons you can now activate the silent
mode "ON" or deactivate "OFF".
IR CONTROLLER:
Press the "Menu" key until the display shows "INFR". The IR remote control menu is displayed. Press "Enter"
again to select "ON" or "OFF". With the "Up" and "Down" buttons you can now activate the IR remote control "ON"
or deactivate "OFF".
DMX MODE:
To select the DMX mode and set the start address, press "Menu" button until the "ADDR" display appears. Press
"Enter" again to select "4CH" or "9CH" mode. Press "Setup" again to select DMX start address "d1" to "d512". With
the "Up" and "Down" buttons, you can now set the desired start address.
MASTER / SLAVE OPERATION:
The "VENTUS XL" can be linked to other devices. To set a device as a "slave", press the "Menu" key until "Slav"
appears in the display. Confirm with the "Enter" key. Select the desired program from the master device. The
interconnected devices now work synchronously.
DISPLAY REVERSE:
Press the "Menu" button until "disp" is displayed. You can now use the "Up" and "Down" buttons to select whether
the display should be set for normal use "dISP" or for use via head "d.SIP". Confirm with the "Enter" key. The
display can thus be adjusted so that it also displays correctly when the head is mounted overhead.
IRC-Remote activated.
IRC-Remote de-activated.
4 channel DMX mode, then set the start address.
9 channel DMX mode, then set the start address.
Master / Slave mode
Display for normal use.
Display turn-around (für hanging operation)
