5.5 and 5.6.
•
Cut as described under section 6.1.
6.4 Miter cut 0°- 45° and turntable 0°- 45°
(Fig. 1-3, 14)
The crosscut saw can be used to make miter cuts
to the left of 0°-45° and to the right of 0°-45° in
relation to the work surface, with simultaneous
setting of the turntable from 0°-45° to the left or
0°-45° to the right in relation to the stop rail (dou-
ble miter cut).
•
If required, dismantle the clamping device
(8) or mount on the opposite side of the fixed
saw table (18).
•
Move the machine head (4) to its upper posi-
tion.
•
Release the turntable (17) by slackening the
locking screw (14).
•
Use the handle (1) to adjust the turntable (17)
to the angle required (in this connection see
also section 6.2).
•
Retighten the locking screw (14) to secure the
turntable in place.
•
Adjust the miter angle on the machine head
and the stop rail as described under points
5.5 and 5.6.
•
Cut as described under section 6.1.
6.5 Limiting the cutting depth (Fig. 15)
•
The cutting depth can be infinitely adjusted
using the screw (27). Turn the screw (27) in or
out to set the required cutting depth and then
retighten the knurled nut on the screw (27).
•
Check the setting by completing a test cut.
6.6 Sawdust bag (Fig. 2)
The saw is equipped with a debris bag (22) for
sawdust and chips.
The debris bag (22) can be emptied by means of
a zipper at the bottom (1).
6.7 Changing the saw blade (Fig. 1, 16-18)
•
Before changing the saw blade: Remove the
power plug!
•
Wear work gloves to prevent injury when
changing the saw blade.
•
Swing the machine head upwards (4).
•
Undo the screw (z) on the cover plate (f) of
the saw blade.
•
Pull back the adjustable blade guard (6) and
at the same time turn the cover plate to achie-
ve access to the flange bolt.
•
Press the saw shaft lock (5) with one hand
while positioning the Allen key (d) on the
flange bolt (31) with the other hand. The saw
Anl_TC_SM_2131_Dual_SPK1.indb 28 Anl_TC_SM_2131_Dual_SPK1.indb 28
GB
shaft lock (5) engages after no more than one
rotation.
•
Now, using a little more force, slacken the
flange screw (31) in the clockwise direction.
•
Turn the flange screw (31) right out and remo-
ve the external flange (32).
•
Take the blade (7) off the inner flange and pull
out downwards.
•
Carefully clean the flange screw (31), outer
flange (32) and inner flange.
•
Fit and fasten the new saw blade (7) in rever-
se order.
•
Important. The cutting angle of the teeth, in
other words the direction of rotation of the
saw blade (7) must coincide with the direction
of the arrow on the housing.
•
Check to make sure that all safety devices
are properly mounted and in good working
condition before you begin working with the
saw again.
•
Important. Every time that you change the
saw blade, check to see that it spins freely in
the table insert(12) in both perpendicular and
45° angle settings.
•
Important. The work to change and align the
saw blade (7) must be carried out correctly.
6.8 Transport (Fig. 1-3)
•
Retighten the locking screw (14) to secure the
turntable (17) in place.
•
Activate the release lever (3), press the ma-
chine head (4) downwards and secure with
the safety pin (25). The saw is now locked in
its bottom position.
•
Fix the saw's drag function with the locking
screw for drag guide (24) in rear position.
•
Carry the equipment by the fixed saw table
(18).
•
To set up the equipment again, proceed as
described in section 5.2.
6.9 Operating the laser (Fig. 2)
To switch on: Move the ON/OFF switch (37) to
the "I" position to switch on the laser (35). A laser
line is projected onto the material you wish to pro-
cess, providing an exact guide for the cut.
To switch off : Move the ON/OFF switch (37) to
the "0" position.
