4. Proper use
The cable hoist is designed for lifting and lowering
loads in enclosed areas commensurate with the
machine's capacity.
The equipment is to be used only for its prescribed
purpose. Any other use is deemed to be a case of
misuse. The user / operator and not the
manufacturer will be liable for any damage or injuries
of any kind caused as a result of this.
Please note that our equipment has not been
designed for use in commercial, trade or industrial
applications. Our warranty will be voided if the
machine is used in commercial, trade or industrial
businesses or for equivalent purposes.
5. Technical data
Voltage (V)
Rated current (A)
Power consumption (W)
Operating mode
Rated load (kg)
Lifting height (single/double hook) (m)
Rated speed (single/double hook) (m/min)
Diameter of steel cable (mm)
Tensile strength of the steel cable (N/mm²)
Insulation class
Protection class
Drive unit class
Net weight (kg)
Operating mode S3 – 20% - 10 minutes: S3 =
Intermittent mode without influencing the starting
process. This means that the maximum operating
period over a time of 10 minutes is 20% (2.0
minutes).
Only use appliances which are in perfect working
n
order.
Service and clean the appliance regularly.
n
Adapt your working style to suit the appliance.
n
Do not overload the appliance.
n
Have the appliance serviced whenever
n
necessary.
Switch the appliance off when it is not in use.
n
Wear protective gloves.
n
6. Before starting the equipment
Danger!
Before you connect the equipment to the mains
supply make sure that the data on the rating
plate are identical to the mains data.
Always pull out the power plug before making
adjustments to the equipment.
The cable hoist is not suitable for transporting
hot and/or molten masses and in addition it is not
suitable for use at low temperatures or in
aggressive atmospheres.
It is in mechanical group M1.
The service life of the cable hoist is
approximately 8000 cycles (excluding wearing
parts). When the hoist has completed 8000
cycles, all its mechanical parts must be checked
and overhauled.
Read and absorb the operating instructions
before you use the cable hoist.
Ensure that the operator knows how the machine
works and how it should be operated.
230 V ~ 50 Hz
The user should always operate as set out in the
7.0
operating instructions.
1600 The cable hoist is not designed for continuous
operation. Its mode of operation is: Intermittent
S3 20%:10 min
mode without influencing the starting process.
500 / 999
The rated capacity of the machine does not vary
11,5 / 6
due to the position of the load.
8 / 4
6.1 Unpacking
6.0
After opening the packaging, inspect the frame, the
1870
steel cable, the hook and the electric control
B
mechanism for signs of possible transit damage.
IP 54
6.2 Assembly (Fig. 5)
M1
The cable hoist is fitted with two fastening bars (1)
30.2
with which it has to be fastened to a rectangular
tube. The dimensions of the arm must conform with
the size of the fastening bars (1) and must be
capable of supporting twice the rated load. We
recommend that you seek advice from a qualified
technician.
All screws must be tightened correctly. A qualified
technician should check the anchoring of the arm
before the machine is started.
6.3 Block and tackle function (Fig. 6 – 9)
The cable hoist is fitted with a return roller (15) and
an additional hook (16). If these parts are used
correctly, the cable hoist can lift twice its rated load.
Fit the return roller (15) and additional hook (16) as
shown in Figure 6 – 8. The permanent hook (8) must
be attached to the fastening hole (2) (Fig. 9). The
load is now raised by two steel cables, which means
that the cable hoist can lift twice its rated load.
GB
9
