L – Longopac: The machine is equipped with a flexible bag system, in which the dust is collected in a closed system.

Technical data

HxWxL [mm]
Weight [kg]
Inlet [mm]
Hose length Ø 50 [m]
Collecting container [l]
3
Max. flow [m /h]
Negative pressure, max. [kPa]
Power rating [W]
Fine filter, polyester, area [m
Efficiency, fine filter, EN 60335-2-69, Class M [%]
Filter area, HEPA filter [m
Efficiency, fine filter, EN 60335-2-69, Class H [%]
Filter classification, EN 1822-1
Sound level [dB(A)]
o
Air temperature max [ C]
*/ Sound pressure level at 1.6 m height and 1 m distance according to DIN EN ISO 3744 in free field measurement at maximum
air flow.

Operation

Connection
Connect the machine to an electrical outlet with a voltage as per the machine's rating plate specifications. If using an extension
cord, it must be water-resistant. Check the direction of rotation of the motor. For machines with a phase converter, the direction of
rotation can be changed easily. For other machines, an electrician must change the phase sequence.
Filter cleaning
The machine has a filter status indicator that lights up when the filter needs to be cleaned or replaced. The filters must be cleaned
1-2 times a day with continuous use and when the manometer needle is in the red field.
The filters should be cleaned when the manometer is in the red field.
1. Keep the machine switched on and close the throttle at the cyclone inlet. Reset the filter cleaner button.
2. Wait for 5-10 pulses.
3. Switch off the machine.
4. Open the throttle at the cyclone inlet and reset the filter cleaner button.
5. Switch on the machine.
6. Check that the pressure gauge indicates green or that the filter indication lamp is off. If not, repeat the procedure. If the
gauge indicates red or the light is on even after repetition, the fine filter needs to be replaced. If it, despite the filter change,
still indicates red, the vacuum valve must be checked.
2
]
2
]
DC 5900, Art.nr. 42838-I
9,2 kW P, c/a/L 9,2 kW S, c/a
1942x780x1160 1942x780x1160
210 200
Ø108 Ø108
5-30 5-30
60/75 /longopac 60/75
800 500
28 40
9,2 9,2
8,4 5
99,9 99,9
3,7 3,7
99,995 99,995
HEPA H13 HEPA H13
75 75
30 30
