Technical Specifications

Technical Specifications
General
Power requirements 200–240V~, 50/60 Hz
Power consumption Operation : Maximum 26W
Dimensions(approx.) 430 *92 *312 (w*h*d)
Mass (approx.)
Operating temperature 5°C to 35°C
Operating humidity
Signal system
Recording
Recording formats
Recordable discs
Recordable time
Video recording format
Sampling frequency 27MHz
Compression format MPEG 2
Audio recording format
Sampling frequency 48kHz
Compression format MPEG1 Layer2
VCR Specifications
Head system
Timer
Tape speed
Tape width
Rewind time
Channel coverage
Frequency range
Signal-to-noise ratio 43 dB
Dynamic range
Channel separation
DVD Specifications
Laser system
Frequency response DVD (PCM 48 kHz): 8 Hz to 22
Video S/N
Audio S/N
Harmonic distortion
˘ ` 57 mac001
Standby : 5W
4.96 Kg
5% to 90%
SECAM Colour
DVD Video Recording, DVD-
VIDEO
DVD±R, DVD±RW
[DVD] (Approx.) 1 hour (HQ
mode), 2 hours (SP mode), 4
hours (EP mode), 8 hours
(SEP mode)
[VCR] SP: 3 Hours (E-180),
LP : 6 Hours (E-180)
4 Head Video, 2 Head Hi-Fi
helical scan azimuth system
24-hour display type
SP: 23.39 mm/sec
LP: 11.70 mm/sec
12.7 mm
less than 150 sec (E-180)
VHF:2-12,13-20,74-80 /
UHF:21-69 / CATV:1-41
20Hz to 20kHz
75 dB
45 dB
Semiconductor laser,
wavelength 650 nm
kHz, CD: 8 Hz to 20 kHz
More than 60 dB
More than 90 dB
Less than 0.06%
1200DPI 100LPI
Dynamic range More than 90 dB
Resolution Over 500 lines (HQ Recording)
Inputs
Antenna In Antenna or CATV input, 75
Video In 1.0 Vp-p 75 , sync negative,
RCA jack x 2
Audio In -8.8 dBm more than 47 k, RCA
jack (L, R) x 2
Outputs
Video Out Composite output (1.0 Vp-p,
unbalanced) RGB output (75 in
load, R:0.7Vp-p, G:0.7Vp-p,
B:0.7Vp-p)
Component Video Out (Progressive Scan)
(Y) 1.0 V (p-p), 75 , negative
sync, RCA jack x 1
(Pb)/(Pr) 0.7 V (p-p), 75 ,
RCA jack x 2
Audio Out Digital audio : 0.5 V (p-p), 75
, RCA jack x 1
Analog audio : 1.1 Vrms (1kHz,
-6 dB), 600 , RCA jack (L, R)
x 2
HDMI video/audio output
19 pin (HDMI standard, Type
A)
Accessories
RF cable .................................................................. 1
Remote control ........................................................ 1
Batteries .................................................................. 2
