6. Installation

Instructions for how to mount the camera are described in the quickstart guide for the relevant IP
camera IPCBXXXX.
When mounting the dome camera IPCB74500 please make sure that the desiccant
bag supplied is placed inside the camera before placing on the dome. The bag must
be placed close to the base plate. The bag must not be in the field of view of the
lens. The bag must not be placed directly behind the lens or the camera board.
6.2

Routing the cables

You must pay attention to the following instructions when laying the cables:
IPCB24500
A break-out panel for feeding the cable is located on the base plate for laying the cables at the
side. Use pliers to remove the break-out panel. Use a file to smooth out the edges of the break-
out panel.
IPCB34500
A break-out panel for feeding the cable is provided for laying the cables at the side. Use a flat,
narrow screwdriver to remove the break-out panel from the plastic.
IPCB64500
A break-out panel for feeding the cable is located on the base plate for laying the cables at the
side. Use pliers to remove the break-out panel. Use a file to smooth out the edges of the break-
out panel.
IPCB72500
For this type of camera, the cable is intended to be laid at the side or concealed. There are
openings at the side and on the base for this. The unused opening is sealed using a blind plug.
For installation the supplied cable gland must be used (for the side and base) in accordance with
protection class IP66. When using the optional wall bracket (TVAC31310), the cable gland may
be omitted, as the wall bracket panel and dome camera have been manufactured to fit together
tightly.
