A
C
L
K
J
A. 21" (53.3 cm) on 21" (53.3 cm) models
B. Combustible area above countertop (shown by dashed box above)
C. 30" (76.2 cm) minimum clearance between top of cooktop
platform and bottom of unprotected wood or metal cabinet (24"
[61 cm] minimum clearance if bottom of wood or metal cabinet is
protected by not less than 1/4" [0.6 cm] flame retardant millboard
covered with not less than No. 28 MSG sheet steel,
0.015" [0.04 cm] stainless steel or 0.024" [0.06 cm] aluminum or
0.020" [0.05 cm] copper)
D. 13" (33 cm) recommended upper cabinet depth
E. 3" (7.6 cm)
F.
151/2" (34.4 cm) on 21" (53.3 cm) models
G. 18" (45.7 cm) minimum clearance from upper cabinet to
countertop within minimum horizontal clearances to cooktop
H. Junction box or outlet; 12" (30.5 cm) minimum from bottom of
countertop; 10" (25.4 cm) from right side of cabinet
I.
18
⁄
" (33.7 cm) on 21" (53.3 cm) models
5
8
J.
1" (2.5 cm) minimum distance to nearest left and right side
combustible surface above cooktop
K. 1
⁄
" (3.4 cm) max. counter thickness on 21" (53.3 cm) models.
5
16
See following illustration
L.
1" (2.5 cm) minimum clearance between back wall and countertop
Product Dimensions
A
D
A. 16¹⁄₂" (41.9 cm)
B. 21" (53.3 cm)
C. 18" (47.7 cm) overall
D. 2⁷⁄₈" (7.3 cm)
Installation Clearances
D
B
F
G
E
H
H
I
B
C
NOTES: After making the countertop cutout, some installations
may require notching down the base cabinet side walls to clear
the burner box. To avoid this modification, use a base cabinet
with sidewalls wider than the cutout.
If cabinet has a drawer, a 3" (7.6 cm) depth clearance from the
countertop to the top of the drawer (or other obstruction) in base
cabinet is required.
When installing a hood above this cooktop, follow the installation
instructions included with the hood itself.
rear of cabinet or
rear wall under
countertop
back edge
of cutout
B
A
A.
/
" (1.7 cm) min.
11
16
B. 1
/
" (3.4 cm) max.
5
16
3
