Voltage sensing and power supply kit
CONNECTION KIT DIAGRAM
>
Standard configuration
• Black wires: switch I
• Red wires: switch II
>
In top cable entry configuration (sources
connected from the top)
• Black wires: switch II
• Red wires: switch I
Example: 4 wires kit (4 poles)
≤ 630 A
Kit connection on
power switches terminals
1-2 3-4 5-6
1-2 3-4 5-6
Red wires
7-8 5-6 3-4
206 205 204
Connection on power supply and control module
SOCOMEC - Réf.: 531 848 F
1
1 3 5 7
I
2
2 4 6 8
≥ 800 A
1-2
7-8
7-8
1-2
1-2
B A
mechanical cables
support
203 202201
Automatic Transfer Switch ATyS
>
Wires numbers
Wires numbers have been determined in accordance
to power switches terminals
Example: black and red wires 1-2 always connected to
terminals 1 or 2 from switch I or II.
3 5 7
II
4 6 8
3-4 5-6
3-4 5-6
Black wires
7-8 5-6 3-4
B A
101 102 103 104
CONNECTIONS
7-8
7-8
1-2
105 106
