Control circuits ATyS 3e
Denomination Terminals Description
Power supply 101 Source
102
201 Source
202
Control 313 Control inhibition
(impulse mode if closed with 317
contactor 314 Position II order if closed with 317
mode to 315 Position I order if closed with 317
change 316 Position 0 order if closed with 317
programming) 317 Specific voltage supply
Common control terminals 313 to 316
Position 13 Common I - 0 - II
auxiliary 14 AC position I NO
contact 24 AC position II NO
34 AC position 0 NO
Auxiliary 43 Auto / manu selector position
contact 44 Closed in automatic position
/ AUT & 53 Padlocked information
padlock 54 Closed if padlock is in place
Fault relay 63 Relay closed when product is faulty
64 (if product is powered)
Second 81 Commun AC position I
auxiliary 82 AC position I NC
contacts 84 AC position I NO
(option) 91 Commun AC position II
92 AC position II NC
94 AC position II NO
Option 0 Connection RS485
Communication -
+
Option I13 + Input
2 Inputs / I14 - Transfer control
2 Outputs I23 + Input
I24 - Source
O13 Load shedding output
O14
023 Fault Output relay
024
SOCOMEC - Réf.: 531 848 F
1
2
2 available
Automatic Transfer Switch ATyS
CONNECTIONS
Characteristics
220 to 240 Vac ±20 %
do not connect to any
power supply
5A AC1 / 250 V
5A AC1 / 250 V
5A AC1 / 250 V
5A AC1 / 250 V
to power from 10 to 30 Vdc 1.5 mm
to power from 10 to 30 Vdc 1.5 mm
5A AC1 / 250 V
Recommended
section
1.5 mm 2
1.5 mm 2
1.5 mm 2
1.5 mm 2
1.5 mm 2
2
1.5 mm
2
2
1.5 mm 2
