Nobles TYPHOON 1610P Manuel Opérateur page 53

BASE & HANDLE GROUP (PUMP- -OUT) / GRUPO BAJO Y DEL MANGO (BOMBA) /
REF PART # DESCRIPTION
1 160482 DHOSE, VACUUM, 2.00ID X 013.0L,
BLK
2 140308 CLAMP
3 700461 VALVE, GATE
4 100096 DGASKET, VACUUM TUBE
5 100381 ELBOW, VACUUM TUBE
6 140197 SCREW, #10- -24X3/8 TRSPHL
7 120657 LABEL, PUMP- -OUT INSTR.
8 230334 HANDLE, AIR VALVE
9 230493 SPACER
10 230338 BRACKET, AIR VALVE
11 210231 VALVE, DRAIN
12 100302 HOUSING, VACUUM MOUNT
13 41169 NUT, 1/4- -20 HEXLK
14 140000 WASHER, 1/4 FLAT
15 100038 DGASKET, VACUUM MOTOR
∇ 16 130415 DMOTOR, VACUUM 120V
190161 DBRUSH, CARBON (2/PK)
Y
17 2998.28 SCREW, 1/4- -20X3- -1/2 HXHDCP
18 100095 DGASKET, VACUUM MOTOR
19 230331.BK PLATE, COVER
20 140900 SCREW, #10- -24X3/4 TRSPHL
21 230746 BRACKET, AXLE
22 103019 CAP, HUB
23 602744 SCREEN, GATE VALVE
24 103068
DWHEEL
25 140063 WASHER, FLAT, 0.51B 1.25D .31
26 608908 AXLE
27 140519 NUT, #10- -24 KEP
28 140195 SCREW, 1/4- -20X1/2 TRSPHL
29 140000 WASHER, 1/4 FLAT
30 180613 DFLOAT, SCREEN SHUT- -OFF
ASSEMBLY / CONJUNTO / ENSEMBLE
∇
INCLUDED IN ASSEMBLY / INCLUIDO A CONJUNTA / Y COMPRIS EN
Y
ENSEMBLE
RECOMMENDED STOCK ITEM / PIEZAS RECOMENDADAS EN ALMACÉN /
D
ELÉMENTS DE STOCK RECOMMANDÉS
Tyhoon 1610P/1612 (08- -07)
PARTS LIST - LISTA DE PIEZAS - LISTE DES PIÈCES
GROUPE BAS ET DE POIGNÉE (POMPE)
QTY.
1
3
1
1
1
4
1
1
1
2
1
1
3
3
1
1
1
3
1
1
1
2
2
1
2
2
1
3
6
5
1
Home Find... Go To..
REF PART # DESCRIPTION
701059 ASM., DRAIN HOSE PUMPOUT
∇
31 160458 HOSE, DRAIN
Y
32 11531 CLAMP
Y
33 608314 DOWNSPOUT, PVC 1- -1/2"
Y
34 140899 SCREW, #10- -24X1- -1/4 RNDPHL
35 140011 WASHER, .18 FLAT
36 1006649 PLUG, DRAIN HOSE
Y
37 230394.BK BRACKET, DRAIN HOSE
38 140825 SCREW, #6X1/2 PANPHL
39 140552 NUT, #10- -24 NYLK
40 607498 TAPE, BUMPER 1/16X1 (3.2 FT)
41 102531 FILTER, FOAM
42 608620 HOUSING, FLTR, RM- -SPG,
TRIMMED (GREEN)
43 160459 DHOSE, VAC W/CUFF
230905 DTUBE, INLET
44 19066 WASHER, #10 FLAT
45 140341 SCREW, #10- -24X1 PANPHL
46 140504 NUT, CONDUIT
47 140003 WASHER, 1/4 FENDER
48 130041 WIRE TIE
49 11531 CLAMP
50 140824 SCREW, 1/4- -20X5/8 TRSPHL
51 578244000 WASHER, M6.4 LOCK
52 230496.BK BRACKET
53 02994 SCREW, 3/8- -16X3/4 HEXHD
54 140017 WASHER 3/8 LOCK
55 140028 WASHER 3/8 FLAT
56 130670AM DBREAKER, CIRCUIT 12A
57 140022 DWASHER, 3/8 LOCK
58 01696 SCREW, 1/4- -20X1/2 HEXHD
59 140016 WASHER, 1/4 LOCK
60 608618 HANDLE, 12/16GAL, RM- -SPGN,
TRIMMED (GREEN)
61 N/A LABEL, CSA
QTY.
1
1
1
1
1
1
1
1
4
1
1
1
1
1
1
4
4
1
3
1
1
2
2
1
2
2
2
1
1
4
4
1
1
53
