10 | English
marks by Robert Bosch Power Tools GmbH is under li-
cense.
Product Description and
Specifications
Read all the safety and general instructions.
Failure to observe the safety and general in-
structions may result in electric shock, fire
and/or serious injury.
Please observe the illustrations at the beginning of this oper-
ating manual.
Intended use
The power tool is intended for making straight cuts in wood
with and against the grain and mitre cuts in wood while rest-
ing firmly against the workpiece.
®
With the Bluetooth Low Energy Module GCY 42 inserted,
power tool data and settings can be transferred between the
power tool and a mobile device by means of Bluetooth
less technology.
Product features
The numbering of the product features refers to the diagram
of the power tool on the graphics page.
(1) Lock-off button for on/off switch
(2) On/off switch
A)
(3) User interface
(4) Auxiliary handle
(5) Adjusting lever for mitre/bevel angle preselection
(6) Wing bolt for parallel guide
(7) Scale for mitre/bevel angles
(8) Cut mark 45° (0° on GKS 18V-68 GC)
(9) Cut mark 0° (45° on GKS 18V-68 GC)
(10) Spindle lock button
(11) Parallel guide
(12) Retracting blade guard
(13) Base plate
(14) Adjusting lever for retracting blade guard
Technical data
Hand-held circular saw
Article number
Rated voltage
A)
No-load speed
Max. cutting depth
– at a 0° mitre/bevel angle
– at a 45° mitre/bevel angle
– at a 50° mitre/bevel angle
Spindle lock
1 609 92A 5MD | (19.03.2020)
(15) Wing bolt for mitre/bevel angle preselection
(16) Protective guard
(17) Cutting depth scale
(18) Chip ejector
B)
(19) Battery
(20) Cover for GCY 42 Bluetooth® Low Energy Module
(21) GCY 42 Bluetooth® Low Energy Module
(22) Button for cutting depth preselection
(23) Lever for cutting depth preselection
(24) Handle (insulated gripping surface)
(25) Saw spindle
(26) Mounting flange
(27) Circular saw blade
(28) Clamping flange
(29) Clamping bolt with washer
(30) Battery release button
®
wire-
(31) Hex key
B)
(32) Dust/chip box
(33) Pair of screw clamps
(34) Battery charge indicator (user interface)
(35) ECO mode indicator (user interface)
(36) Button for speed preselection (user interface)
(37) Speed stage/mode indicator (user interface)
(38) Smartphone indicator (user interface)
(39) Power tool status indicator (user interface)
(40) Temperature indicator (user interface)
B)
(41) Guide rail
(42) Extraction hose
(43) Connection piece
(44) Groove for Bosch and Mafell guide rail systems
(45) Groove for Festool and Makita guide rail systems
A) only for GKS 18V-68 GC
B) Accessories shown or described are not included with the
product as standard. You can find the complete selection of
accessories in our accessories range.
GKS 18V-68 GC
3 601 FB5 1..
V=
–1
min 2500–5000
mm
mm
mm
A)
B)
A)
B)
B)
B)
A)
A)
A)
A)
A)
A)
A)
B)
A)B)
A)
GKS 18V-68 C
3 601 FB5 0..
18 18
5000
68 70
49.8 49.5
45.8 44.4
●
Bosch Power Tools
A)
●
