08
The T-valve is properly installed as the build-in filter keeps out the impurities from the tap water
1. ATTACH THE MULTICLIN
CLICK!
2. CONNECT T-VALVE AND HOSES
Tank
Water inlet
Bidet Hose
T-Valve
Water Supply Hose
Water shutoff
valve
3. TRIAL OPERATION
Turn on the water shutoff valve slowly. Ensure the connections are not
leaking before continuing.
4. POWER SUPPLY CONNECTION
Make sure to keep hands dry. Insert the power plug into a outlet.
5. FUNCTIONAL TEST
Sit on MULTICLIN and press cleaning buttons to fill water reservoir.
Do not plug-in the product before completion of installation thoroughly.
Failure to do so could result in product breakdown.
Note:MULTICLIN is equipped with an automatic touch sensor to
detect the presence of the user.
If the seat is not occupied, cleaning function will not work.
CONNECT T-VALVE AND HOSES
IMPORTANT!
Slide the MULTICLIN on to the mounting plate. You will hear a "Clicking"
indicating the seat has been properly attached.
First of all install the MULTICLIN and connect it to water supply and
finally to the power supply.
To remove the product
Push the button and pull the product towards you for releasing.
T-valve must be installed
properly with all
connections before
continuing. Failure to
do so could conduct
water leakage.
IMPORTANT!
Use wrench to tighten all connections
before continuing.
WARNING
If your tank is built into the wall,
please install the
stopper nut on the
T-valve to connect
the tap water
shutoff valve to
MULTICLIN directly.
WARNING
Wrong Connections
YP-23
YUNG-LI
10-16
250
