7.8
Connection of external measuring devices
You may connect external measuring devices (e.g. Multimeters) to the
RS232 interface of the MultiSystem 5060 and assign the measuring signals
to a special channel. The measuring devices must support the output data
format "Voltcraft" or "Metex".
Configuration in the channel menu
You can assign the output signal of the external device to any special
channel. Open the parameters of the desired channel in the channel menu
(see section 6.3.4 on page 20) and set the parameter "Calculation" to
"RS232".
Then you will have to select the output signal type of the device ("Voltcraft
VC 820", "Metex", or "Voltcraft VC 9x0") and assign a name to the channel.
Press
to save the channel settings. Then you may use this channel for
display, recording and calculations as any other channel.
