Mounting the monitor
Connecting the monitor to an electricity supply (fig. f, page 10)
7.4
The circuit diagram for the monitor can be found in fig. f, page 10.
No. Description
1 Monitor
2 13-pin DIN plug
3 Connection cable
4 13-pin DIN socket
5 12 V positive cable (red): Connection to the positive pole of the voltage source
6 Earth cable (black): Connection to the negative pole of the voltage source
7 6-pin DIN socket
8 Cable (green): Control input for the connection to the reversing lights
9 6-pin mini DIN plug
10 System cable
11 6-pin mini DIN socket
12 6-pin mini DIN plug
13 Camera
Observe the following instructions when laying the connection cable:
• Feed the connection cable through existing ducts or other openings where possible e. g. ven-
tilation grilles. If no appropriate ducts or openings are available you will need to drill a hole of
 18 mm. Check beforehand that there is sufficient space on the other side for the drill head to
come out (fig. 2, page 4).
• Please observe the notes from the chapter "General information on the electrical connections"
on page 16.
➤ Lay the monitor cable on the dashboard.
➤ Insert the plug of the monitor cable (2) in the socket (4) of the connection cable (3).
A
NOTICE!
Make sure the polarity is correct when connecting to a voltage source.
➤ Connect the red and black cables of the connection cables to a suitable voltage source:
– Connect the red cable (5) to terminal 15 (ignition).
– Connect the black cable (6) to terminal 31 (earth).
➤ If necessary, connect the mini DIN socket (7) of the connection cable to the mini DIN plug (9)
of the system cable (10).
