Using the LCD monitor
Changing parameters
➤ Press the "S" button (8) to call up the required parameter.
➤ Press the "–" button (4) to reduce the value of the selected parameter.
➤ Press the "+" button (5) to increase the value of the selected parameter.
8.5 Setting the display mode
To set the display mode, proceed as follows (fig. 0, page 6):
➤ If you would like to switch to a display mode, press the "
✓ The monitor runs through the different display modes.
I
NOTE
If you want the cameras to run automatically: see chapter "Setting the auto-
matic search" on page 38.
8.6 Setting the automatic search
Proceed as follows to set the automatic search (fig. 0, page 6):
➤ Select the "System setup" sub-menu, "Autoscan" parameter.
➤ Press the "–" button (4) or the "+" button (5) to open the automatic search.
➤ Press the "M" button (7) until the menu closes.
✓ The monitor starts the cameras in the order "Camera 1 – Camera 2 – Camera 3 –
Camera 4" automatically in the preset time.
After the first run through, only the inputs with connected cameras are shown.
No sound is available in this operating mode.
Setting the display time
You can set the display time from 1 to 60 s.
➤ Select the "System setup" sub-menu, "Scan delay" parameter.
➤ Press the "–" button (4) to reduce the camera display time.
➤ Press the "+" button (5) to increase the camera display time.
Quitting the automatic search
➤ Select the "System setup" sub-menu, "Autoscan" parameter.
➤ Press the "–" button (4) or the "+" button (5) to switch off the automatic search.
38
PerfectView M9LQ
" button (6).
