Adjusting the Convergence
The adjustment data becomes the common setting for all
input signals.
1
Press the CONV button.
The "CONVERGENCE" OSD (On Screen Display)
appears.
CONV
2
For vertical adjustment
Press the > >/. buttons.
> . . . to move Red up and Blue down
. . . . to move Red down and Blue up
For horizontal adjustment
Press the ¨ ?// buttons.
? . . . to move Red to the right and Blue to the left
/ . . . to move Red to the left and Blue to the right
To erase the "CONVERGENCE" OSD, press the CONV
button again.
The "CONVERGENCE" OSD automatically disappears
10 seconds after you release the buttons.
To reset, press RESET button while the OSD is on.
CONVERGENCE
0 2 3
Setteing the Color Temperature
The selected color temperature becomes the common setting
for all input signals. (The factory presetting is 9300K.)
1
Press COLOR button.
The "COLOR TEMPERATURE" OSD (On Screen
Display) appears.
COLOR
SELECT
2
Adjust with the > >/. and ¨ ?// buttons.
To select 9300K, 6500K, or 5000K
Press > >/. buttons.
To obtain the desired color temperature between
5000K and 9300K
1 Press > >/. buttons to select user mode (
SELECT
2 Press ¨ ?// buttons.
? . . . for lower temperature (to be reddish)
/ . . . for higher temperature (to be blueish)
Your most recent adjusted color temperature will be
recalled by pressing > >/. button.
The factory presetting is 6500K for the user adjustable
mode of color temperature.
To erase the "COLOR TEMPERATURE" OSD, press the
COLOR button again.
The "COLOR TEMPERATURE" OSD automatically
disappears 10 seconds after you release the buttons.
To reset, press RESET button while the OSD is on.
COLOR TEMPERATURE
9300K
6500K
5000K
50
).
COLOR TEMPERATURE
9300K
6500K
5000K
50
SET
