SPECIFICATIONS

Model Name:
Product Type:
Type:
Number of Channels:
Mono Channels:
Mono Mic/Line Input Channels:
Mono Mic/Line Input Connections:
Mono Mic Input Type:
Frequency Response Mono Mic Input:
Amplification Range Mono Mic Input:
Channel Crosstalk:
THD Mono Mic Input:
Impedance Mono Mic Input:
S/N Ratio Mono Mic Input:
Mono Line Input Type:
Amplification Range Mono Line Input:
THD Mono Line Input:
Impedance Mono Line Input:
S/N Ratio Mono Line Input:
Mono Channel Equalizer Treble:
Mono Channel Equalizer Mids:
Mono Channel Equalizer Bass:
Channel Insert:
Channel Insert Connections:
Phantom Power:
Low Cut:
Hi-Z:
Compressor:
Control Elements Channel 1 - 16:
LDVIBZ24DC
analogue mixer
live / home recording
24
16
6.3 mm stereo jack, XLR
electronically balanced, discreet design
10 - 45,000 Hz
50 dB
90 dB
0.0058%
4 kOhm
113 dB
electronically balanced, discreet design
50 dB
0.0045%
21 kOhm
116 dB
+/-15 dB @ 12 kHz
+/- 15dB @ 200 Hz - 8 kHz
+/-15 dB @ 80 Hz
Channel 1 - 8
6.3 mm stereo jack (TIP= send / RING= return)
+48 V DC switchable to XLR inputs
95 Hz
jack input channel 1-4 switchable (> 50 kOhm)
Channel 1 - 8
Gain, Low Cut, High-Z (channels 1 - 4),Compressor (channels 1 - 8), EQ Hi, EQ Mid, EQ
Mid Freq, EQ Low, EQ on/off, DFX, AUX Send 1-2 pre (AUX2 pre/post switchable), AUX
Send 3-4 post, Channel Mute, Fader Routing switch (Group 1/2, Group 3/4, Main L+R),
Pan/Bal, Channel-Fader, PFL switch
