10.3.2.5 UPnP™

The UPnP (Universal Plug and Play) function makes it easy to control network devices in an IP network. This
allows the network encoder to be seen in the Windows network environment (e.g. as a network device).
Enable UPnP
For enabling or disabling the UPnP function.
Name
Display of the MAC address of the camera
Port Mapping
Enable Port Mapping
This enables Universal Plug and Play port forwarding for network services. If your router supports UPnP, then
port forwarding for video streams is automatically enabled on the router for the network encoder using this
option.
Port Mapping Mode
Select here whether you wish to conduct port mapping automatically or manually.
You can choose between 'Auto' and 'Manual'.
Protocol Name:
HTTP
The default port for HTTP transmission is 80. As an alternative, this port can be assigned a value in the range
1025 ~ 65535. If several IP cameras/encoders are located on the same subnetwork, each device should have
its own unique HTTP port
RTSP
The default port for RTSP transmission is 554. As an alternative, this port can be assigned a value in the
range 1025 ~ 65535. If several IP cameras/encoders are located on the same subnetwork, each device
should have its own unique RTSP port
Server Port (control port)
The standard port for SDK transmission is 8000. Communication port for internal data. As an alternative, this
port can be assigned a value in the range 1025 ~ 65535. If several IP cameras/encoders are located on the
same subnetwork, each device should have its own unique SDK port
External Port
