ARVA Link Mode D'emploi page 16

Setting your device - Conf iguration menu
To access the Confi guration menu whenever you wish, you must:
Switch off the device (press top right button, then validate switch-off with centre
button: see page 5, diagram
Hold down the left- and right-hand buttons simultaneously
While still holding these two buttons down, press the On/Off button 2 for 5 se-
conds 2 .
Selecting a language (default: English)
To select a language, scroll down the list using the two up/down arrows, and
validate with the centre button.
The language options are French, English, German, Italian and Spanish.
To enter your contact details, proceed in the same way. If you do not want to enter
your details now, select EXIT.
Entering your contact details
You have three lines of alphanumerical marks. We advise you to start with your
surname and fi rst name, to identify your device in case of loss.
The fi rst telephone number can be the owner's. The second can be a number to
call in case of emergency.
This information is displayed each time the device is switched on.
Calibrating the compass
This allows the direction indicator to react quickly, and lets the device know if your
search direction is correct. To work correctly, the compass must be calibrated,
especially if you have made a long journey or changed the batteries.
To start calibrating, place the device on a fl at surface and access the Calibration
tab. Keeping the device horizontal, rotate it clockwise until calibration ends. The
device then automatically reverts to the confi guration menu and displays "Cali-
bration OK".
Selecting a search mode
The default mode is Novice. We advise you to start in this mode. The device will
automatically search for the nearest victim, and the only available function is mar-
king of the found victim, in case of multi-victim burial. After marking, the device
will then automatically switch to the next detected victim.
In Expert mode, you can select the victim you want to search for, mark/unmark
victims, and obtain more information using W-Link technology.
Selecting a W-Link region (default: region A)
The W-Link frequency is a protected radio frequency, with rights that must be
respected, depending on the country you are in.
Some countries do not accept the use of this frequency on their territory. In such
cases, the W-Link function in the confi guration must be deactivated.
The user is solely responsible for changing or deactivating this frequency. The
manufacturer can in no event be held responsible for any change to or non-ma-
nagement of this right of frequency use in the country where the device is used.
16
5
)
3
4
(default: Novice)
1
1
2
1
5"
3
Mode:
4
Novice
Expert
