Storage
There is no limitation on the storage of the appli-
ance indoors provided that the cylinder is removed
from the appliance.

Between uses:

• Turn control knob OFF.
• Turn gas cylinder OFF.
Store heater upright in an area sheltered from di-
rect contact with inclement weather (such as rain,
sleet, hail, snow, dust and debris).
If desired, cover to protect exterior surfaces and to
prevent build up in air passages.
Note: Wait until heater is cool before covering.
Troubleshooting
IF THE PROBLEM IS
Pilot won't light
EN
Pilot won't stay lit
Burner won't light
Burner flame is low
Note: Do not operate heat-
er below 5°C (40°F)
Emitter glows uneven
Note: Bottom 2.5cm of
emitter normally does not
normally glow
Carbon build-up
Thick black smoke
14
AND THIS CONDITION EXISTS
Cylinder valve is closed
Blockage in orifice or pilot tube
Air in the gas line
Low gas pressure
Igniter fails
Dirt build up around pilot
Connection between gas valve and pilot
assembly is loose
Thermocouple is not operating
correctly
Gas pressure is low
Blockage in orifice
Control knob is not in "ON" position
Gas pressure is low
Outdoor temperature is greater than 5°C
(40°F) and tank is less than 25% full
Supply hose is bent or kinked
Control knob is fully " ON"
Gas pressure is low
Base is not on a level surface
Heater not level
Dirt or film on reflector and emitter
Blockage in burner
During periods of extended inactivity or when
transporting:
• Turn control knob OFF.
• Disconnect gas cylinder and move to a secure,
well ventilated location outdoors. DO NOT store
in a location that will exceed 50°C.
Store heater upright in an area sheltered from di-
rect contact with inclement weather (such as rain,
sleet, hail, snow, dust and debris).
If desired, cover heater to protect exterior surfaces
and to prevent build up in air passages.
Note: Wait until heater is cool before covering
THEN DO THIS
Open valve
Clean or replace orifice or pilot tube
Open gas line and bleed it (pressing control knob in)
for not more than 1-2 minutes or until you smell gas
Replace propane gas (disposable) cylinder with a
new cylinder
Use match to light pilot (with match holder, see
picture**); obtain new igniter and replace
Clean dirt from around pilot
Tighten connection and perform leak test
Replace thermocouple
Replace propane gas (disposable) cylinder with a
new cylinder
Clear blockage
Turn control knob to "ON" position
Replace gas cylinder
Replace gas cylinder
Straighten hose and perform leak test on hose
Turn control knob to "OFF", let it cool to room tem-
perature and check burner and orifices for blockage
Replace gas cylinder
Place heater on a level surface
Level heater
Clean reflector and emitter
Turn control knob to "OFF", let it cool to room temper-
ature and remove blockage and clean burner inside
and outside.
