Assembly; Display And Connections; Electrical Connection - Kemper 611 00 Manuel D'utilisation

EN
4
4.1
1 Reset button
2 2-colour LED for function control
3 MicroSC card slot
Note!
Insert the microSD card into the card slot as shown (contact facing up).
4.2
Connect the data logger with the CAN bus
and mini-USB cable present in the cold water
cooler.
18/ 64 – K410061100000-00 – 07.2020 – © www.kemper-olpe.de

Assembly

Display and connections

Electrical connection

4 Mini USB
5 Ethernet
6 CAN bus (2x)
