Fixing

• Trace the median line on the wall, choose a comfortable height for
the user and trace it on the wall to make montage easier (1-2).
• Determine the X and Y dimensions and mark the position of the two
holes with a pencil. Then carry out the perforation (2 x Ø 12 mm);
insert the two hooks with dowels (3).
• Remove the fat filter (4), hang the hood up, adjust its horizontal po-
sition with the adjustment screws (5).
• Mark the position of the 2/4 holes on the wall (6).
Remove the hood and carry out the perforation (2/4 x Ø 8 mm). In-
sert the dowels into the holes.
• Fix the flue support bracket (7A – Suction version) or the deflector
(7F – Filtering version) with the Ø 8 mm dowels and the Ø 5x45
mm screws at 3-4 mm distance from the ceiling with the hood cen-
tred and perfectly horizontal.
• Hand the hood up again, fixing it definitively (8) with the screws (2/4
x Ø 5x45 mm).
• Fix the reduction tube (9) above the hood with two Ø 3 x 9 mm
screws.
• Use a tube long enough to reach the outside (10) or the deflector
(7F – Filtering version).
• Connect the electricity (11) (see "Electric connection" chapter).
• Apply the flue (12) and fix it to the support bracket with 2 Ø 3x9 mm
screws or to the deflector with 4 Ø 3.5x13 mm screws. Let the lower
part of the flue slide down and apply the upper part over the hood
(13).
• Mount the fat filter.
