Oven And Accessories - Sharp R-200 Mode D'emploi

2
1
9 8
10
13
Hub (inside)
15. Turntable
(glass)
17. Coupling
NOTES:
• The waveguide cover is fragile. Care should be taken when cleaning inside the oven to ensure that it is not
damaged.
• Always operate the oven with the turntable and turntable support fitted correctly. This promotes thorough,
even cooking. A badly fitted turntable may rattle, may not rotate properly and could cause damage to the oven.
• All food and containers of food are always placed on the turntable for cooking.
• The turntable rotates clockwise or anti-clockwise. The rotary direction may change each time you start the
oven. This does not affect cooking performance.
R-200_OM_BOOKLET_WEST.indb Sek2:3 R-200_OM_BOOKLET_WEST.indb Sek2:3
3
5
14
6 4
7
11
12
16. Turntable
support

OVEN AND ACCESSORIES

OVEN
1. Door
2. Door hinges
3. Oven lamp
4. Waveguide cover (DO NOT REMOVE)
5. Control panel
6. Coupling
7. Door latches
8. Oven cavity
9. Door seals and sealing surfaces
10. Door safety latches
11. Ventilation openings
12. Outer cabinet
13. Power supply cord
14. Door opening button
ACCESSORIES:
Check to make sure the following accessories are
provided:
(15) Turntable (16) Turntable support (17) Coupling
Place the turntable support in the centre of the oven
floor so that it can freely rotate around the coupling.
Then place the turntable on to the turntable support
so that it locates firmly into the coupling. To avoid
turntable damage, ensure dishes and containers are
lifted clear of the turntable rim when removing them
from the oven.
NOTE: When you order accessories, please mention
two items: part name and model name to your
dealer or SHARP authorised service agent.
GB-3
