14. Spare parts

Rev. Change no
1 7799
5*
6
CASSETTE 2
13 12*
CASSETTE 1
14*
POS. PART. NO.
1 713472
2 714455
3 714730
3 714816
3* 714731
3* 714817
4 713600
5 714835
5* 714736
6 714600
7 410522
8 102258
9 713783
10 713782
11 714844
11* 714845
12 714653
12* 714828
13 714829
14 714839
14* 714840
15 711293
16* 121496
16* 102483
17 120295
Material
Drawn date
2016-11-10
714812 rev 2
Change description
0- SERIE
4
9 10
17
5
FOOT
PILLAR STAND (IRT 4-1/4-2 COMBI IR-UVA)
CONTROL UNIT (IRT 4-1 COMBI IR-UVA)
CONTROL UNIT (IRT 4-10 COMBI IR-UVA)
CONTROL UNIT (IRT 4-2 COMBI IR-UVA)
CONTROL UNIT (IRT 4-20 COMBI IR-UVA)
ARM COMPLETE (WITHOUT POS 9, 10 AND 11)
CASSETTE ARM (IRT 4-1/4-10 COMBI IR-UVA)
CASSETTE ARM (IRT 4-2/4-20 COMBI IR-UVA)
CASSETTE COMPLETE
CASTOR DIA. 100mm
CASTOR BRAKED 125mm
PROTECTION PLATE RIGHT
PROTECTION PLATE LEFT
GASSPRING 1000N (IRT 4-1/4-10 COMBI IR-UVA)
GASSPRING 1600N (IRT 4-2/4-20 COMBI IR-UVA)
HARNEST TO CASSETTE (IRT 4-1/4-10 COMBI IR-UVA)
HARNEST CASSETTE 1 (IRT 4-2/4-20 COMBI IR-UVA)
HARNEST CASSETTE 2 (IRT 4-2/4-20 COMBI IR-UVA)
PYROMETER KIT INCL LASER AND DISTANCE SENSOR (IRT 4-1/4-10 COMBI IR-UVA)
PYROMETER KIT INCL LASER AND DISTANCE SENSOR (IRT 4-2/4-20 COMBI IR-UVA)
POWER CABLE 10m (IRT 4-1/4-2 COMBI IR-UVA)
POWER CONNECTOR (P 316-6 3P DEPENDING ON MARKET)
POWER CONNECTOR (P 416-6 4P DEPENDING ON MARKET)
ADJUSTMENT BOLT
Surface finish
Approved by Drawn by
AL
Certified by
Description
SPARE PART LIST MOBIL
3*
2
1
8
7
DESCRIPTION
Dimension Note
Designed by General Tolerance
AL ISO 2768-m
Rev. by Appr. by Appr. date
AL AL 2016-11-11
11*
15
16*
701039
Scale Sheet
1:20 E 1 (5)
Status
Approved
Article no Rev
701039
1
