Functionality of connections
Connection diagram
The functionality of different connections can be configured with microswitches
S1 - S5. The original factory status is documented on the connection diagram.
If required, the alternative functionality shown in the connection diagram can be
made available by switching the corresponding microswitch.
Sample connection diagram:
Analogue outputs in socket #1 and M-Bus in socket #2.
62
CALEC
ST II
®
