Environnement système de l'interface audio R16
Pour utiliser le logiciel DAW avec cette unité, vous devez l'installer et faire ses réglages pour l'employer
avec le R16. L'explication qui suit concerne la procédure avec Cubase LE4.
Configurations informatiques
requises pour l'interface audio R16
Windows
®
Windows XP SP2 ou ultérieur/Windows
ou ultérieur
® ®
Pentium 4 Intel 1,8 GHz ou plus rapide
1Go de RAM minimum
Mac Intel
OS X 10.4.11 ou ultérieur/10.5 ou ultérieur
Processeur Core Duo Intel
TM
rapide
1Go de RAM minimum
Pour les deux
Port compatible USB 2.0
* Les systèmes d'exploitation 64 bits ne sont
pas pris en charge.
* Les concentrateurs (hubs) USB ne sont pas
pris en charge.
À propos des copies d'écran
Les copies d'écran concernent la version
Windows.
À propos des marques déposées
· Le symbole SD et le symbole SDHC
® ®
· Windows /Windows Vista sont des marques commerciales ou déposées de Microsoft
® ®
· Macintosh , Mac OS et Logic sont des marques commerciales ou déposées d'Apple Inc.
· Steinberg et Cubase sont des marques commerciales ou déposées de Steinberg Media Technologies GmbH Inc.
® ®
· Intel et Pentium sont des marques commerciales ou déposées d'Intel Corporation.
®
· AMD Athlon sont des marques commerciales ou déposées d'Advanced Micro Devices, Inc.
· MACKIE Control est une marque commerciale ou déposée de LOUD Technologies.
· SONAR est une marque commerciale ou déposée de Cakewalk, Inc.
· Ableton Live est une marque commerciale ou déposée d'Ableton AG.
· Digital Performer est une marque commerciale ou déposée de Mark of the Unicorn.
· Les autres marques commerciales, noms de produit et noms de société mentionnés dans cette documentation sont la
propriété de leurs détenteurs respectifs.
· Toutes les marques commerciales et déposées mentionnées dans ce mode d'emploi ne le sont que dans un but d'identification
et non dans le but d'enfreindre les droits de leurs détenteurs respectifs.
®
Vista SP1
1,83 GHz ou plus
®
sont des marques commerciales.
Guide d'installation de Cubase LE 4
Veuillez vous référer au guide de prise en main de
Cubase LE 4/USB pour des instructions détaillées
sur l'installation du pilote audio R16 et de Cubase
LE 4.
Cubase LE 4 Startup Guide
Windows Vista / XP This Cubase LE 4 Startup Guide explains how to install Cubase LE 4 on a computer, make connections and other settings for the R16.
To connect the R16 to a computer running Windows Vista Start InstallShield Wizard
(or Windows XP) and to enable audio input/output, proceed Click [Next] to start
as follows. The installation description uses Windows Vista
installation.
as an example.
Insert the supplied "Cubase LE 4" DVD-ROM into
the DVD drive of the computer.
When you insert the DVD-ROM, a screen asking what you want
to do appears. Select "Open folder to view files".
When the contents of the DVD-ROM are shown, open the Driver-Plug In selection screen
Cubase LE 4 for Windows folder by double-clicking on it, and
If you use SONER,
then double-click the executable "Setup" ("Setup.exe") file to start
s e l e c t I n s t a l l a t i o n
the installation process.
Plug In for Control
Surface.
HINT
If nothing happens when you insert the DVD-ROM, open the Start
menu and select "Computer" ("My Computer" in Windows XP). Then
double-click the "Cubase LE 4" DVD-ROM icon to display the contents Ready to install the program
of the DVD-ROM.
Click [Install] to start
NOTE installation.
To use Cubase LE 4 continuously, it is necessary to have the User
Registration and the Software License Authentication. The Registration
and Authentication are available to be processed when Cubase LE 4 is
activated on a computer connected to the internet. Click "Register now"
which is shown when activating, enter all the items. If it is not recognized
as Registration, Cubase LE 4 can only be used for a limited period after
installation.
"PDF Manuals and Drivers" CD-ROM supplied with R16
If a warning dialogue "Install software" appears, click [Continue].
Drivers>Windows "Setup.exe" If a warning dialogue "Windows security Driver Software Licensee
or cannot be verified." appears, click [Install this driver software].
Download the latest "ZOOM R16 Audio Driver" from
ZOOM homepage (http://zoom.co.jp)
and install it on a computer. *A message "ZOOM R16 Audio Driver (No Response)" may appear,
but it is not a problem. Wait until it responds.
ZOOM R16 Audio Driver software is required to enable use of
Cubase LE 4 for audio input and output with a computer. Refer InstallShield Wizard was completed
to the read_me file included in the download package for
Click [Complete] to
instructions on how to install the driver correctly.
finish installation.
[How to install the driver]
Double-click Setup.exe file to activate the installer.
Set language selection
Choose language and
click [OK].
NOTE
We recommend you upgrade the system software to the latest version on
the R16. An R16 operated on an old system may not be recognized
correctly. The latest version can also be downloaded from our homepage.
®
.
Set and connect the R16 to the computer When the connection is completed on the R16, it is recognized
using a USB cable. by the computer.
If this is the first time to connect the R16, wait until the message
How to set and connect the R16
"Your devices are ready to use" appears.
1
Start "Found New hardware Wizard"
Press.
Choose [No, not this
2
Select t i m e ] o f W i n d o w s
Update and click[Next].
Menu moves Press.
3
Execute.
Press.
4
Select of how to continue settings.
C h o o s e [ I n s t a l l t h e
Menu moves
Press.
software automatically]
5 and click [Next]to start
Connect USB cable to the R16
installation.
[DEVICE] flashes
USB indicator
AUDIO INTERFACE flashes
If a warning dialogue "Install hardware" appears, click [Continue].
6
"Found New Hardware Wizard completed"
Connect USB cable
Click [Finish] to complete installation.
to computer
When the connection operation of the R16 is finished, it is
recognized by the computer.
When connecting for the first time please wait until the message
of "The device was able to be prepared" is displayed.
INTERFACE flashes when the connection is complete Connection setting completed
Bring up the "Sound" window from the Control Panel
and make the input device setting for the computer.
To bring up the "Sound" window, select "Control Panel" from the
[INPUT 1-8]Jack [PHONES]Jack Start menu and click "Hardware and Sound", then click "Sound".
Guitar, other instrument or Audio system,
built-in stereo mic headphones or other
playback equipment
R16
[OUTPUT]Jack
Windows PC
Audio components,
amp built-in
DAW software
speakers etc
Cubase LE 4 etc
USB cable
In the "Sound" window, verify that "R16 Audio Interface" is listed
ZOOM R16 Audio Driver
under the Play and Record devices and that the device is
checked. (To switch between Play and Record, click the tabs at
NOTE
the top of the window.)
Use a high-quality USB cable and keep the connection as short as If the device is not checked, right-click on the icon for the device
possible. If USB bus power is supplied to the R16 via a USB cable and click "Set as Default Device" so that a check mark appears.
which is more than 3 meters in length, the low voltage warning
Continued overleaf
indication may appear.
