CONNECTING TO Connect all components before plugging any power cords into the wall outlet.
THE CABLE TV Always turn off the DVB-T receiver, TV and other components before you
SIGNAL AND TV: connect or disconnect any cables.
Do not attempt to service this product yourself.
SERVICING Any attempt to do so will make the warranty invalid.
Refer all servicing to a qualified service agent.
If the DVB-T receiver is installed in an area subject to intense lightning
activity, protection equipment for the DVB-T receiver's mains connector are
essential.
LIGHTNING
The individual manufacturer's instruction for safeguarding other equipment,
such as a TV set, Hi-Fi, etc., connected to the DVB-T receiver must also be
followed during lightning storms.
Note:
Dispose the used batteries at a designated place for environmental protection.
4. Packaging content
• 1 receiver
• 1 remote control
• 1 user manual
5. Technical specifications:
TUNER & CHANNEL
BAND WIDTH
DEMODULATOR
DECODER
TRANSPORT STREAM
PROFILE LEVEL
DECODER MODULE
INPUT RATE
VIDEO FORMATS
Audio Format
VIDEO OUTPUT
MEDIA PLAYER
RF INPUT CONNECTOR x1
(D-7YPE, IEC169-2, FEMALE)
RF OUTPUT CONNECTOR x1
(D-TYPE, IEC169-2, MALE (LOOPTHROUGH))
FREQUENCY RANGE:
1 74 MHz – 230 MHz (VHF) & 470 MHz – 862 MHz (UHF)
SIGNAL LEVEL:
-10 ~ -70 dBm
7/8 MHz
COFDM
MPEG-2 ISO/IEC 13818-1
MPEG-2 MAIN PROFILE @MAIN LEVEL,
PAL-NTSC-AUTO
MAX. 15Mbit/s
4:3/16:9 SWITCHABLE
MPEG Layer I & II, 32 / 44.1 / 48 kHz
CVBS,RGB
JPEG, BMP, MP3, MPG (MPEG2)
