5.3 Connection
Risk of electroshock! Touching live wires can cause life-
threatening electroshocks.
 Have the device repaired by qualified personnel.
 Disconnect the power source.
 Cover and shield any adjacent live components.
 Ensure the device cannot be switched on.
 Make sure the power supply is disconnected.
1. Connect the necessary cables according to the wiring scheme on
the detector's housing. Make sure all connections are tightly
secured.
2. Switch on the power. Proceed with the test.
5.4

Testing the Detector
