Symbols
The following symbols are important for reading and under-
standing the operating instructions. Please take note of the
symbols and their meaning. The correct interpretation of the
symbols will help you to use the machine in a better and safer
manner.
Symbol Meaning
GSB 12V-15:
Combination Cordless Drill
Grey-marked area: Handle (insulated
gripping surface)
Article number
Read all safety warnings and all
instructions
Before any work on the machine itself,
remove the battery
Always wear ear protection.
Movement direction
Reaction direction
Right/left rotation
Screwdriving
Drilling without impact
Impact drilling
Low speed
High speed
Switching On
Switching Off
1 609 92A 2N1 | (22.7.16)
Symbol Meaning
Battery Charge Indicator
U Rated voltage
n 1 No-load speed (1. gear)
0
n 2 No-load speed (2. gear)
0
n Impact rate
S
M Maximum torque according to ISO 5393
Brickwork
Metal
Wood
Ø Drilling diameter, max.
Ø Max. screw dia.
Chuck clamping range
Weight according to EPTA-Procedure
01:2014
* Value dependent of the battery pack
being used
L Sound power level
wA
L Sound pressure level
pA
K Uncertainty
a Vibration total value
h
T Permitted ambient temperature during
1
charging
T Permitted ambient temperature during
2
*
operation and storage
* limited performance at temperatures
<0 °C
Recommended batteries
Recommended chargers

Delivery Scope

Combination cordless drill.
Battery, application tools and other accessories shown or de-
scribed are not part of the standard delivery scope.
A complete overview of accessories can be found in our ac-
cessories program.

Intended Use

The machine is intended for driving in and loosening screws
as well as for drilling in wood, metal, ceramic and plastic and
for impact drilling in brick, brickwork and masonry.
The light of this power tool is intended to illuminate the power
tool's direct area of working operation and is not suitable for
household room illumination.
