6. Drainset configuration and electrical connection

Basic principles

A filling system must be connected and configured.
If a pulse water meter is integrated in the drainset, it is important not to connect a filling pulse water meter too, and monitor
it with, the SPC control unit, and vice versa.
The configuration and electrical connections can be carried out in various ways, depending on the system equipment with NSP
and drainset.
Please refer to the following tables for standard configurations under Lfd.- No. 1 to 3.
NSP filling
Ser.
No. Assembly
1 NSP in unit
with WZ
(Standard)
2 NSP in unit
with IWZ
(Option for
Standard)
3 NSP in unit
with WZ
(Standard)
4 NSP pipe string
with
MV and WZ
5 NSP pipe string
with
MV and IWZ
6 NSP pipe string
with
MV and WZ
*here corresponding to volume monitoring as the IWZ is connected
IWZ connection (pwm):
If the drainset contains an IWZ (AS-IWZ 16 or 20), this must be wired to terminals 8 and 9 of the SPC (market pwm). (In these
circumstances, the prerequisite is that the filling system does not contain an IWZ or that this IWZ is not wired to the SPC and not
analysed by the SPC.)
The terminalplan can be found in the Appendix of these documentation. Please find the software settings in
Doc.- No.: MC00018/01-2012/eng section: Main menu, input and operating menu, configuration variants.
8
Terminals for software
the MV of the configuration of
NSP in the SPC for NSP
SPC
18,19,20 230V
self-monitored
(time)
18,19,20 230V
self-monitored*
230V
18,19,20 self-monitored
(time)
potential-free
15,16,17 self-monitored
(time)
potential-free
15,16,17 self-monitored*
potential-free
15,16,17 self-monitored
(time)
AS_drainset Terminals software
for configuration of
Assembly SPC for AS
MV in SPC
AS-WZ-16
or 20 15,16,17 potential-free
registered (time)
AS-WZ-16
or 20 15,16,17 potential-free
registered (time)
AS-IWZ-16 potential-free
or 20 15,16,17
self
-monitored*
AS-WZ-16
or 20 18,19,20 230V
registered (time)
AS-WZ-16 230V
or 20 18,19,20
registered (time)
230V self-
AS-IWZ-16
or 20 18,19,20 monitored*
Terminals terminal
plan
for IWZ
in SPC No. . .
for AS
- 1
8.9 1
8.9 1
- 2
8.9 2
8.9 2
