4.1.2 Attaching the shearing head

Risk of injury caused by sharp cut-
ting plates!
Handle the shearing head of
WARNING Clipper FAV5 with appropriate
caution.
Note
The shearing head GT330 #10 (USA+UK) for Clipper
FAV5 is included in the scope of delivery. Various shear-
ing heads are available for different applications!
1
Fig. 1
If the hinge is closed: Open hinge 1 with a
screwdriver, see Fig. 1.
12
Fig. 2
1
Install shearing head 12 on open hinge 1, see Fig. 2.
Press ON/OFF switch 3.
Fig. 3
Slightly push shearing head 12 towards Clipper
FAV5, see Fig. 3.
Shearing head 12 will click into position.
Check that shearing head 12 is correctly seated on
Clipper FAV5.

4.2 Function checks for Clipper FAV5

Carry out a visual inspection.
Check the switch position.
Install the cutting set correctly and lubricate it if
necessary, see Chapter Treatment of the cutting
set.
Clean the Clipper FAV5 prior to use, see Chapter
Cleaning/Disinfecting.
