Signal timings
Display mode
VESA
US text
Power Macintosh
series
Notes:
- All are compliant only with non-interlaced.
- Frequencies for Power Macintosh are reference values.
- If the monitor is receiving timing signals that are not compatible, [OUT OF TIMING] will appear. Follow
your computer's instruction manual to set the timing to be compatible with the monitor.
- If the monitor is not receiving any signal (synch signal), [NO SIGNAL] will appear.
The connector pin
5 4
10 9
15 14
Mini D-sub connector with 15 pins
Specifications
Hsync (kHz)
31.5kHz
640x480 37.9kHz
37.5kHz
35.1kHz
37.9kHz
800x600
48.1kHz
46.9kHz
48.4kHz
1024x768 56.5kHz
60.0kHz
720x400 31.5kHz
640x480 35.0kHz
832x624 49.7kHz
1024x768 60.2kHz
Number
3 2 1
1
8 7 6
13 12 11
2
3
4
5
6
7
8
9
10
11
12
13
14
15
23
Dot frequency
Vsync (Hz)
(MHz)
60Hz 25.175MHz
72Hz 31.5MHz
75Hz 31.5MHz
56Hz 36.0MHz
60Hz 40.0MHz
72Hz 50.0MHz
75Hz 49.5MHz
60Hz 65.0MHz
70Hz 75.0MHz
75Hz 78.75MHz
70Hz 28.3MHz
66.7Hz 30.2MHz
74.6Hz 57.3MHz
75Hz 80.0MHz
Function
Red video signal input
Green video signal input
Blue video signal input
GND
GND
For red video signal GND
For green video signal GND
For blue video signal GND
+ 5V
GND
N.C.
DDC data
For H-sync signal input
For V-sync signal input
DDC clock
