SPECIFIC SAFETY RULES FOR TRIMMER USE
Make sure all guards, straps, deflectors and handles
■
are properly and securely attached.
Use only the manufacturer's replacement line in the
■
cutting head. Do not use any other cutting attachment.
Never operate unit without the grass deflector in place
■
and in good condition.
Maintain a firm grip on both handles while trimming.
■
Keep string head below waist level. Never cut with
the string head located over 76 cm or more above the
ground.
SPECIFIC SAFETY RULES FOR
BRUSHCUTTER AND BLADE USE
After engine stops, keep rotating blade in heavy grass
■
or pulpy weeks until it stops.
Do not operate the brushcutter unless the blade guard
■
is firmly secured in place and in good condition.
Use heavy gloves while installing or removing blades.
■
Always stop the engine and remove the spark plug
■
wire before attempting to remove any obstruction
caught or jammed in the blade or before removing
and installing the blade.
Do not attempt to touch or stop the blade when it is
■
rotating.
A coasting blade can cause injury while it continues
■
to spin after the engine is stopped or throttle trigger
released. Maintain proper control until the blade has
completely stopped rotating.
Replace any blade that has been damaged. Always
■
make sure blade is installed correctly and securely
fastened before each use. Failure to do so can cause
serious injury.
Use only the manufacturer's replacement TRI-ARC
■
blade intended for use on this brushcutter. Do not use
any other blade.
The TRI-ARC blade is suited for cutting pulpy weeds
■
and vines only. Do not use for any other purpose.
Never use the TRI-ARC blade to cut woody brush.
Exercise extreme caution when using the blade with
■
this unit. Blade thrust is the reaction that may occur
when the spinning blade contacts anything it cannot
cut. This contact may cause the blade to stop for an
instant, and suddenly "thrust" the unit away from the
object that was hit. This reaction can be violent enough
to cause the operator to lose control of the unit.
Blade thrust can occur without warning if the blade
snags, stalls, or binds. This is more likely to occur in
areas where it is difficult to see the material being
P NL S DK N FIN GR HU CZ RU RO PL SLO HR TR EST LT
English
cut. For cutting ease and safety, approach the weeds
being cut from the right to the left. In the event an
unexpected object or woody stock is encountered,
this could minimize the blade thrust reaction.
Never cut any material over 13 mm diameter.
■
Always wear the shoulder strap when using the
■
brushcutter and adjust to a comfortable operating
position. Maintain a firm grip on both handles while
cutting with a blade. Keep the blade away from body
and below waist. Never use the brushcutter with the
blade located 76 cm or more above the ground level.
Cover the blade with the blade protector before
■
storing the unit, or during transportation. Always
remove the blade protector before using the unit.
If not removed, the blade protector could become a
thrown object as the blade begins to turn.
SPECIFICATION
Weight
- Without fuel, cutting attachment
- With blade
- With string head
Fuel tank volume
Cutting swath
Engine displacement
Maximum engine performance
(in accordance with ISO 8893)
Maximum rotational frequency
of the the spindle
Engine speed (rotational frequency)
at recommended max. spindle
rotational frequency
Engine speed (rotational frequency)
at idle
Fuel consumption (in accordance
with ISO 8893) at max.
engine performance
Specific fuel consumption
(in accordance with ISO 8893)
at max. engine performance
Vibration level with blade
- Front handle
- Rear handle
Vibration level with string head
- Front handle
- Rear handle
Value to declare
[in accordance with NF EN ISO 22867
(Feb 2006) and EN ISO 11806 (Jun 1997)]
Sound pressure level
(in accordance with NF EN ISO 22868)
Sound power level
16
LV SK BG
5.56 kg
5.75 kg
5.65 kg
620 cm 3
457 mm
25.4 cm 3
0.9 kW
1
10,000 min-
12,500 min- 1
2,600-3,200 min- 1
0.54 kg/h
0.50 kg/h
2
8.7 m/s
2
12.2 m/s
2
22.7 m/s
2
7.3 m/s
2
22.7 m/s
103dB(A)
112dB(A)
